| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_071T54_9000004482_31021cztM0_level2.evt | modeM0/AS1A10_071T54_9000004482_31021cztM0_level2_quad_clean.evt |
| Size (bytes) | 538,594,560 | 91,313,280 |
| Size | 513.6 MB | 87.1 MB |
| Events in quadrant A | 3,203,482 | 607,943 |
| Events in quadrant B | 5,205,267 | 615,402 |
| Events in quadrant C | 3,563,807 | 562,778 |
| Events in quadrant D | 3,918,387 | 545,561 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13183 | 2 |
| B | 0 | 19312 | 2 |
| C | 0 | 14195 | 2 |
| D | 0 | 15444 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 24 | 0 |
| B | 0 | 25 | 0 |
| C | 0 | 25 | 0 |
| D | 0 | 25 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 128 | 0 |
| B | 0 | 128 | 0 |
| C | 0 | 128 | 0 |
| D | 0 | 128 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6202 | 32 | 0.515963% |
| B | 6202 | 111 | 1.789745% |
| C | 6201 | 227 | 3.660700% |
| D | 6201 | 181 | 2.918884% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7567 | 6203 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7567 | 6203 | 8 | 8 | 0.11% | 0.13% |  |
| C | 7566 | 6202 | 129 | 129 | 1.70% | 2.08% |  |
| D | 7566 | 6202 | 142 | 142 | 1.88% | 2.29% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 11666 | 65.54 | 831 | 817 | 165.5 |
| A | 3 | 137 | 7912 | 42.86 | 831 | 817 | 165.5 |
| A | 0 | 226 | 7108 | 38.0 | 831 | 817 | 165.5 |
| B | 6 | 159 | 1799899 | 11631.09 | 829 | 810 | 154.7 |
| B | 0 | 190 | 61522 | 392.5 | 829 | 810 | 154.7 |
| B | 4 | 52 | 31620 | 199.19 | 829 | 810 | 154.7 |
| C | 0 | 10 | 353265 | 1942.95 | 778 | 786 | 181.4 |
| C | 14 | 238 | 128540 | 704.21 | 778 | 786 | 181.4 |
| C | 1 | 16 | 24183 | 128.97 | 778 | 786 | 181.4 |
| D | 8 | 195 | 414044 | 2244.08 | 776 | 758 | 184.2 |
| D | 13 | 174 | 317086 | 1717.61 | 776 | 758 | 184.2 |
| D | 13 | 249 | 117371 | 633.19 | 776 | 758 | 184.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
