| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C06_002T01_9000004490_31064cztM0_level2.evt | modeM0/AS1C06_002T01_9000004490_31064cztM0_level2_quad_clean.evt |
| Size (bytes) | 558,224,640 | 115,044,480 |
| Size | 532.4 MB | 109.7 MB |
| Events in quadrant A | 3,081,215 | 776,749 |
| Events in quadrant B | 5,457,886 | 774,807 |
| Events in quadrant C | 3,466,058 | 773,325 |
| Events in quadrant D | 4,490,044 | 735,368 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13019 | 1 |
| B | 0 | 20621 | 1 |
| C | 0 | 14246 | 1 |
| D | 0 | 17337 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 124 | 0 |
| B | 0 | 124 | 0 |
| C | 0 | 124 | 0 |
| D | 0 | 124 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6068 | 39 | 0.642716% |
| B | 6069 | 203 | 3.344867% |
| C | 6069 | 178 | 2.932938% |
| D | 6069 | 163 | 2.685780% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7418 | 6069 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7419 | 6070 | 37 | 37 | 0.50% | 0.61% |  |
| C | 7419 | 6070 | 37 | 37 | 0.50% | 0.61% |  |
| D | 7419 | 6070 | 96 | 96 | 1.29% | 1.58% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 13071 | 79.09 | 795 | 781 | 155.4 |
| A | 12 | 96 | 10379 | 61.76 | 795 | 781 | 155.4 |
| A | 3 | 137 | 6984 | 39.92 | 795 | 781 | 155.4 |
| B | 6 | 159 | 1972316 | 13789.7 | 791 | 775 | 143.0 |
| B | 0 | 183 | 99587 | 691.13 | 791 | 775 | 143.0 |
| B | 4 | 67 | 77537 | 536.9 | 791 | 775 | 143.0 |
| C | 0 | 10 | 133668 | 740.02 | 784 | 791 | 179.6 |
| C | 14 | 238 | 126888 | 702.26 | 784 | 791 | 179.6 |
| C | 3 | 233 | 80290 | 442.75 | 784 | 791 | 179.6 |
| D | 8 | 195 | 911158 | 4926.24 | 780 | 762 | 184.8 |
| D | 13 | 174 | 254624 | 1373.67 | 780 | 762 | 184.8 |
| D | 13 | 249 | 135657 | 729.93 | 780 | 762 | 184.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
