| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_109T01_9000004492_31095cztM0_level2.evt | modeM0/AS1A10_109T01_9000004492_31095cztM0_level2_quad_clean.evt |
| Size (bytes) | 557,196,480 | 107,478,720 |
| Size | 531.4 MB | 102.5 MB |
| Events in quadrant A | 3,308,452 | 714,680 |
| Events in quadrant B | 5,293,814 | 712,304 |
| Events in quadrant C | 3,699,103 | 687,646 |
| Events in quadrant D | 4,122,761 | 676,499 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13937 | 2 |
| B | 0 | 20224 | 2 |
| C | 0 | 15022 | 2 |
| D | 0 | 16785 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 134 | 0 |
| B | 0 | 134 | 0 |
| C | 0 | 134 | 0 |
| D | 0 | 134 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14 | 0 |
| B | 0 | 15 | 0 |
| C | 0 | 15 | 0 |
| D | 0 | 15 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6658 | 30 | 0.450586% |
| B | 6658 | 136 | 2.042655% |
| C | 6658 | 249 | 3.739862% |
| D | 6658 | 54 | 0.811054% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7583 | 6659 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7583 | 6659 | 0 | 0 | 0.00% | 0.00% |  |
| C | 7583 | 6659 | 28 | 28 | 0.37% | 0.42% |  |
| D | 7583 | 6659 | 9 | 9 | 0.12% | 0.14% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 14190 | 77.93 | 857 | 844 | 171.3 |
| A | 3 | 137 | 8530 | 44.88 | 857 | 844 | 171.3 |
| A | 0 | 226 | 7026 | 36.1 | 857 | 844 | 171.3 |
| B | 6 | 159 | 1912379 | 11700.97 | 849 | 827 | 163.4 |
| B | 12 | 111 | 19833 | 116.34 | 849 | 827 | 163.4 |
| B | 0 | 190 | 18487 | 108.1 | 849 | 827 | 163.4 |
| C | 0 | 10 | 230923 | 1181.05 | 831 | 839 | 194.8 |
| C | 14 | 238 | 135017 | 688.75 | 831 | 839 | 194.8 |
| C | 10 | 22 | 69648 | 353.2 | 831 | 839 | 194.8 |
| D | 13 | 174 | 485079 | 2415.54 | 837 | 817 | 200.5 |
| D | 8 | 195 | 427913 | 2130.39 | 837 | 817 | 200.5 |
| D | 2 | 234 | 25652 | 123.88 | 837 | 817 | 200.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
