| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C06_002T02_9000004518_31223cztM0_level2.evt | modeM0/AS1C06_002T02_9000004518_31223cztM0_level2_quad_clean.evt |
| Size (bytes) | 672,249,600 | 124,594,560 |
| Size | 641.1 MB | 118.8 MB |
| Events in quadrant A | 3,125,349 | 900,358 |
| Events in quadrant B | 6,169,649 | 814,602 |
| Events in quadrant C | 3,723,885 | 837,954 |
| Events in quadrant D | 6,936,299 | 802,157 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 124 | 0 |
| B | 0 | 124 | 0 |
| C | 0 | 124 | 0 |
| D | 0 | 124 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12883 | 1 |
| B | 0 | 22233 | 1 |
| C | 0 | 14879 | 1 |
| D | 0 | 24908 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5978 | 145 | 2.425560% |
| B | 5979 | 907 | 15.169761% |
| C | 5979 | 284 | 4.749958% |
| D | 5979 | 655 | 10.955009% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7248 | 5979 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7249 | 5979 | 460 | 460 | 6.35% | 7.69% |  |
| C | 7249 | 5980 | 70 | 70 | 0.97% | 1.17% |  |
| D | 7249 | 5979 | 462 | 462 | 6.37% | 7.73% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 12002 | 69.68 | 807 | 792 | 160.9 |
| A | 5 | 16 | 8356 | 47.01 | 807 | 792 | 160.9 |
| A | 3 | 137 | 7129 | 39.39 | 807 | 792 | 160.9 |
| B | 6 | 159 | 1610179 | 11871.35 | 737 | 722 | 135.6 |
| B | 4 | 80 | 1385237 | 10212.18 | 737 | 722 | 135.6 |
| B | 0 | 190 | 178723 | 1312.93 | 737 | 722 | 135.6 |
| C | 0 | 10 | 278425 | 1598.02 | 756 | 759 | 173.8 |
| C | 15 | 208 | 216627 | 1242.36 | 756 | 759 | 173.8 |
| C | 14 | 238 | 131074 | 749.99 | 756 | 759 | 173.8 |
| D | 8 | 195 | 3385472 | 17155.68 | 758 | 744 | 197.3 |
| D | 13 | 249 | 311226 | 1573.69 | 758 | 744 | 197.3 |
| D | 2 | 250 | 102132 | 513.89 | 758 | 744 | 197.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
