| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C06_006T06_9000004520_31238cztM0_level2.evt | modeM0/AS1C06_006T06_9000004520_31238cztM0_level2_quad_clean.evt |
| Size (bytes) | 293,863,680 | 38,836,800 |
| Size | 280.3 MB | 37.0 MB |
| Events in quadrant A | 1,579,655 | 255,686 |
| Events in quadrant B | 3,041,028 | 248,845 |
| Events in quadrant C | 1,677,380 | 236,898 |
| Events in quadrant D | 2,407,631 | 231,419 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 60 | 0 |
| B | 0 | 60 | 0 |
| C | 0 | 60 | 0 |
| D | 0 | 60 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 6377 | 1 |
| B | 0 | 10838 | 1 |
| C | 0 | 6656 | 1 |
| D | 0 | 8954 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 2841 | 112 | 3.942274% |
| B | 2841 | 446 | 15.698698% |
| C | 2841 | 161 | 5.667019% |
| D | 2841 | 200 | 7.039775% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 4091 | 2843 | 0 | 0 | 0.00% | 0.00% |  |
| B | 4091 | 2843 | 169 | 169 | 4.13% | 5.94% |  |
| C | 4091 | 2843 | 24 | 24 | 0.59% | 0.84% |  |
| D | 4091 | 2843 | 128 | 128 | 3.13% | 4.50% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 5 | 16 | 16595 | 198.4 | 405 | 396 | 81.6 |
| A | 13 | 254 | 5343 | 60.59 | 405 | 396 | 81.6 |
| A | 3 | 137 | 3740 | 40.96 | 405 | 396 | 81.6 |
| B | 6 | 159 | 801889 | 10825.83 | 382 | 373 | 74.0 |
| B | 14 | 167 | 605019 | 8166.77 | 382 | 373 | 74.0 |
| B | 10 | 245 | 46164 | 618.49 | 382 | 373 | 74.0 |
| C | 0 | 10 | 98735 | 1100.3 | 378 | 380 | 89.4 |
| C | 14 | 238 | 60898 | 677.01 | 378 | 380 | 89.4 |
| C | 4 | 175 | 12071 | 130.79 | 378 | 380 | 89.4 |
| D | 8 | 195 | 611348 | 6514.7 | 390 | 379 | 93.8 |
| D | 12 | 79 | 234404 | 2495.38 | 390 | 379 | 93.8 |
| D | 2 | 250 | 37409 | 394.85 | 390 | 379 | 93.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
