| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C06_006T06_9000004520_31239cztM0_level2.evt | modeM0/AS1C06_006T06_9000004520_31239cztM0_level2_quad_clean.evt |
| Size (bytes) | 652,222,080 | 93,833,280 |
| Size | 622.0 MB | 89.5 MB |
| Events in quadrant A | 3,158,774 | 632,872 |
| Events in quadrant B | 5,311,717 | 616,332 |
| Events in quadrant C | 3,439,022 | 595,114 |
| Events in quadrant D | 7,424,922 | 564,563 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 128 | 0 |
| B | 0 | 128 | 0 |
| C | 0 | 128 | 0 |
| D | 0 | 128 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13157 | 1 |
| B | 0 | 19962 | 1 |
| C | 0 | 13851 | 1 |
| D | 0 | 26331 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10 | 0 |
| B | 0 | 10 | 0 |
| C | 0 | 10 | 0 |
| D | 0 | 10 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6187 | 105 | 1.697107% |
| B | 6188 | 280 | 4.524887% |
| C | 6188 | 253 | 4.088559% |
| D | 6188 | 668 | 10.795087% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7247 | 6188 | 5 | 5 | 0.07% | 0.08% |  |
| B | 7248 | 6189 | 29 | 29 | 0.40% | 0.47% |  |
| C | 7248 | 6189 | 24 | 24 | 0.33% | 0.39% |  |
| D | 7248 | 6189 | 678 | 678 | 9.35% | 10.95% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 5 | 16 | 31694 | 191.5 | 806 | 789 | 161.4 |
| A | 13 | 254 | 12019 | 69.58 | 806 | 789 | 161.4 |
| A | 11 | 47 | 9793 | 55.79 | 806 | 789 | 161.4 |
| B | 6 | 159 | 1883643 | 12597.01 | 787 | 769 | 149.5 |
| B | 0 | 190 | 146047 | 971.96 | 787 | 769 | 149.5 |
| B | 10 | 245 | 84580 | 560.72 | 787 | 769 | 149.5 |
| C | 0 | 10 | 206171 | 1137.53 | 765 | 769 | 180.6 |
| C | 14 | 238 | 138994 | 765.5 | 765 | 769 | 180.6 |
| C | 3 | 233 | 38970 | 211.56 | 765 | 769 | 180.6 |
| D | 8 | 195 | 2104006 | 10645.61 | 762 | 750 | 197.6 |
| D | 12 | 79 | 1977906 | 10007.36 | 762 | 750 | 197.6 |
| D | 13 | 249 | 156170 | 786.66 | 762 | 750 | 197.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
