| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_053T27_9000004534_31312cztM0_level2.evt | modeM0/AS1A10_053T27_9000004534_31312cztM0_level2_quad_clean.evt |
| Size (bytes) | 218,623,680 | 14,644,800 |
| Size | 208.5 MB | 14.0 MB |
| Events in quadrant A | 1,156,666 | 75,057 |
| Events in quadrant B | 1,805,994 | 72,668 |
| Events in quadrant C | 2,156,151 | 69,051 |
| Events in quadrant D | 1,356,961 | 73,053 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 44 | 0 |
| B | 0 | 44 | 0 |
| C | 0 | 44 | 0 |
| D | 0 | 44 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 9 | 0 |
| B | 0 | 9 | 0 |
| C | 0 | 9 | 0 |
| D | 0 | 9 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 4618 | 1 |
| B | 0 | 6834 | 1 |
| C | 0 | 7899 | 1 |
| D | 0 | 5338 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 2107 | 107 | 5.078310% |
| B | 2107 | 185 | 8.780256% |
| C | 2107 | 831 | 39.439962% |
| D | 2107 | 97 | 4.603702% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 2992 | 2108 | 0 | 0 | 0.00% | 0.00% |  |
| B | 2992 | 2108 | 8 | 8 | 0.27% | 0.38% |  |
| C | 2992 | 2108 | 55 | 55 | 1.84% | 2.61% |  |
| D | 2992 | 2108 | 2 | 2 | 0.07% | 0.09% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 3932 | 58.64 | 299 | 292 | 62.1 |
| A | 3 | 137 | 3146 | 45.98 | 299 | 292 | 62.1 |
| A | 0 | 226 | 2544 | 36.28 | 299 | 292 | 62.1 |
| B | 6 | 159 | 553945 | 9352.42 | 287 | 279 | 59.2 |
| B | 4 | 80 | 99278 | 1672.27 | 287 | 279 | 59.2 |
| B | 0 | 190 | 13468 | 222.79 | 287 | 279 | 59.2 |
| C | 3 | 233 | 871796 | 14699.82 | 243 | 244 | 59.3 |
| C | 14 | 254 | 153136 | 2578.72 | 243 | 244 | 59.3 |
| C | 14 | 238 | 144039 | 2425.28 | 243 | 244 | 59.3 |
| D | 8 | 195 | 221992 | 3091.35 | 291 | 283 | 71.7 |
| D | 12 | 79 | 13721 | 187.37 | 291 | 283 | 71.7 |
| D | 2 | 234 | 9010 | 121.68 | 291 | 283 | 71.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
