| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_053T27_9000004534_31318cztM0_level2.evt | modeM0/AS1A10_053T27_9000004534_31318cztM0_level2_quad_clean.evt |
| Size (bytes) | 669,427,200 | 85,233,600 |
| Size | 638.4 MB | 81.3 MB |
| Events in quadrant A | 3,790,588 | 526,092 |
| Events in quadrant B | 6,894,192 | 518,429 |
| Events in quadrant C | 4,420,004 | 501,237 |
| Events in quadrant D | 4,647,327 | 499,109 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 156 | 0 |
| B | 0 | 156 | 0 |
| C | 0 | 156 | 0 |
| D | 0 | 156 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 5 | 0 |
| B | 0 | 5 | 0 |
| C | 0 | 5 | 0 |
| D | 0 | 5 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16141 | 1 |
| B | 0 | 25995 | 1 |
| C | 0 | 18005 | 1 |
| D | 0 | 18944 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7714 | 172 | 2.229712% |
| B | 7714 | 756 | 9.800363% |
| C | 7715 | 377 | 4.886585% |
| D | 7715 | 231 | 2.994167% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8154 | 7716 | 1 | 1 | 0.01% | 0.01% |  |
| B | 8154 | 7716 | 193 | 193 | 2.37% | 2.50% |  |
| C | 8155 | 7717 | 17 | 17 | 0.21% | 0.22% |  |
| D | 8155 | 7717 | 33 | 33 | 0.40% | 0.43% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 14886 | 70.1 | 981 | 959 | 198.7 |
| A | 3 | 137 | 10244 | 46.73 | 981 | 959 | 198.7 |
| A | 0 | 226 | 8194 | 36.41 | 981 | 959 | 198.7 |
| B | 6 | 159 | 2103440 | 11611.46 | 931 | 905 | 181.1 |
| B | 5 | 172 | 496940 | 2739.4 | 931 | 905 | 181.1 |
| B | 4 | 80 | 350812 | 1932.4 | 931 | 905 | 181.1 |
| C | 3 | 233 | 476379 | 2169.29 | 926 | 929 | 219.2 |
| C | 14 | 238 | 165493 | 750.84 | 926 | 929 | 219.2 |
| C | 0 | 10 | 110158 | 498.37 | 926 | 929 | 219.2 |
| D | 8 | 195 | 792542 | 3444.93 | 951 | 923 | 229.8 |
| D | 12 | 233 | 153707 | 664.88 | 951 | 923 | 229.8 |
| D | 2 | 234 | 37814 | 160.54 | 951 | 923 | 229.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
