| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_101T01_9000004546_31356cztM0_level2.evt | modeM0/AS1A10_101T01_9000004546_31356cztM0_level2_quad_clean.evt |
| Size (bytes) | 598,492,800 | 77,791,680 |
| Size | 570.8 MB | 74.2 MB |
| Events in quadrant A | 3,612,334 | 478,211 |
| Events in quadrant B | 5,716,901 | 470,089 |
| Events in quadrant C | 3,983,498 | 446,480 |
| Events in quadrant D | 4,323,123 | 457,307 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15025 | 2 |
| B | 0 | 22346 | 2 |
| C | 0 | 16148 | 2 |
| D | 0 | 17550 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 148 | 0 |
| B | 0 | 148 | 0 |
| C | 0 | 148 | 0 |
| D | 0 | 148 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 6 | 0 |
| B | 0 | 6 | 0 |
| C | 0 | 6 | 0 |
| D | 0 | 6 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7223 | 130 | 1.799806% |
| B | 7224 | 266 | 3.682171% |
| C | 7224 | 331 | 4.581949% |
| D | 7224 | 99 | 1.370432% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7878 | 7224 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7879 | 7225 | 15 | 15 | 0.19% | 0.21% |  |
| C | 7879 | 7225 | 6 | 6 | 0.08% | 0.08% |  |
| D | 7879 | 7225 | 5 | 5 | 0.06% | 0.07% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 16618 | 84.19 | 933 | 916 | 186.5 |
| A | 3 | 137 | 9383 | 45.4 | 933 | 916 | 186.5 |
| A | 0 | 226 | 7986 | 37.91 | 933 | 916 | 186.5 |
| B | 6 | 159 | 1923119 | 10918.34 | 909 | 887 | 176.1 |
| B | 10 | 247 | 89979 | 506.05 | 909 | 887 | 176.1 |
| B | 0 | 190 | 87748 | 493.37 | 909 | 887 | 176.1 |
| C | 14 | 238 | 219535 | 1077.26 | 871 | 878 | 203.0 |
| C | 3 | 233 | 169239 | 829.47 | 871 | 878 | 203.0 |
| C | 14 | 254 | 112433 | 549.6 | 871 | 878 | 203.0 |
| D | 8 | 195 | 824246 | 3582.19 | 897 | 877 | 229.9 |
| D | 2 | 234 | 32063 | 135.68 | 897 | 877 | 229.9 |
| D | 2 | 250 | 27673 | 116.58 | 897 | 877 | 229.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
