| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T04_026T01_9000004556_31400cztM0_level2.evt | modeM0/AS1T04_026T01_9000004556_31400cztM0_level2_quad_clean.evt |
| Size (bytes) | 604,935,360 | 86,820,480 |
| Size | 576.9 MB | 82.8 MB |
| Events in quadrant A | 3,641,351 | 542,836 |
| Events in quadrant B | 5,698,031 | 538,322 |
| Events in quadrant C | 4,109,953 | 519,589 |
| Events in quadrant D | 4,371,929 | 515,479 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15259 | 2 |
| B | 0 | 22459 | 4 |
| C | 0 | 16630 | 2 |
| D | 0 | 17765 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 150 | 0 |
| B | 0 | 150 | 0 |
| C | 0 | 150 | 0 |
| D | 0 | 150 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7374 | 187 | 2.535937% |
| B | 7373 | 333 | 4.516479% |
| C | 7373 | 270 | 3.662010% |
| D | 7373 | 307 | 4.163841% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7759 | 7375 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7758 | 7373 | 17 | 17 | 0.22% | 0.23% |  |
| C | 7758 | 7374 | 2 | 2 | 0.03% | 0.03% |  |
| D | 7758 | 7374 | 132 | 132 | 1.70% | 1.79% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 12039 | 58.63 | 943 | 922 | 189.6 |
| A | 3 | 137 | 10159 | 48.72 | 943 | 922 | 189.6 |
| A | 0 | 226 | 7892 | 36.76 | 943 | 922 | 189.6 |
| B | 6 | 159 | 1970943 | 10927.09 | 924 | 898 | 180.3 |
| B | 12 | 18 | 54862 | 299.32 | 924 | 898 | 180.3 |
| B | 12 | 111 | 22891 | 121.99 | 924 | 898 | 180.3 |
| C | 3 | 233 | 366386 | 1715.1 | 899 | 904 | 213.1 |
| C | 14 | 238 | 158391 | 739.04 | 899 | 904 | 213.1 |
| C | 14 | 254 | 23073 | 104.03 | 899 | 904 | 213.1 |
| D | 12 | 218 | 508731 | 2204.44 | 899 | 876 | 230.4 |
| D | 8 | 195 | 314978 | 1363.42 | 899 | 876 | 230.4 |
| D | 10 | 203 | 46867 | 199.63 | 899 | 876 | 230.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
