| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T04_026T01_9000004556_31414cztM0_level2.evt | modeM0/AS1T04_026T01_9000004556_31414cztM0_level2_quad_clean.evt |
| Size (bytes) | 641,568,960 | 84,260,160 |
| Size | 611.8 MB | 80.4 MB |
| Events in quadrant A | 3,923,774 | 511,324 |
| Events in quadrant B | 6,170,471 | 512,918 |
| Events in quadrant C | 4,451,789 | 496,206 |
| Events in quadrant D | 4,356,172 | 489,035 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16 | 0 |
| B | 0 | 16 | 0 |
| C | 0 | 16 | 0 |
| D | 0 | 16 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16324 | 2 |
| B | 0 | 23839 | 2 |
| C | 0 | 17855 | 2 |
| D | 0 | 17766 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 162 | 0 |
| B | 0 | 162 | 0 |
| C | 0 | 162 | 0 |
| D | 0 | 162 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7787 | 245 | 3.146269% |
| B | 7788 | 376 | 4.827940% |
| C | 7788 | 404 | 5.187468% |
| D | 7788 | 207 | 2.657935% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 9427 | 7787 | 0 | 0 | 0.00% | 0.00% |  |
| B | 9428 | 7788 | 8 | 8 | 0.08% | 0.10% |  |
| C | 9428 | 7788 | 45 | 45 | 0.48% | 0.58% |  |
| D | 9428 | 7788 | 11 | 11 | 0.12% | 0.14% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 12504 | 56.12 | 1017 | 996 | 205.0 |
| A | 3 | 137 | 10756 | 47.6 | 1017 | 996 | 205.0 |
| A | 0 | 226 | 8466 | 36.43 | 1017 | 996 | 205.0 |
| B | 6 | 159 | 2130414 | 11098.54 | 992 | 966 | 191.9 |
| B | 4 | 80 | 68776 | 353.42 | 992 | 966 | 191.9 |
| B | 0 | 190 | 39141 | 198.97 | 992 | 966 | 191.9 |
| C | 3 | 233 | 224469 | 976.39 | 969 | 974 | 228.9 |
| C | 10 | 22 | 221496 | 963.4 | 969 | 974 | 228.9 |
| C | 14 | 238 | 179483 | 779.86 | 969 | 974 | 228.9 |
| D | 8 | 195 | 490227 | 2052.87 | 989 | 962 | 238.3 |
| D | 12 | 218 | 61352 | 253.39 | 989 | 962 | 238.3 |
| D | 12 | 79 | 46774 | 192.22 | 989 | 962 | 238.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
