| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_094T26_9000004558cztM0_level2.fits | modeM0/AS1A10_094T26_9000004558cztM0_level2_quad_clean.evt |
| Size (bytes) | 277,934,400 | 188,781,120 |
| Size | 265.1 MB | 180.0 MB |
| Events in quadrant A | 1,768,936 | 1,027,131 |
| Events in quadrant B | 1,639,358 | 1,010,918 |
| Events in quadrant C | 1,730,886 | 1,008,895 |
| Events in quadrant D | 1,534,598 | 923,740 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 53226 | 0 |
| B | 0 | 77287 | 0 |
| C | 0 | 56966 | 0 |
| D | 0 | 62765 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 63 | 0 |
| B | 0 | 63 | 0 |
| C | 0 | 63 | 0 |
| D | 0 | 63 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 520 | 0 |
| B | 0 | 520 | 0 |
| C | 0 | 520 | 0 |
| D | 0 | 520 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 25345 | 144 | 0.568159% |
| B | 25347 | 399 | 1.574151% |
| C | 25348 | 565 | 2.228973% |
| D | 25344 | 385 | 1.519097% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 32091 | 25352 | 0 | 0 | 0.00% | 0.00% |  |
| B | 32091 | 25350 | 0 | 0 | 0.00% | 0.00% |  |
| C | 32091 | 25349 | 0 | 0 | 0.00% | 0.00% |  |
| D | 32091 | 25349 | 0 | 0 | 0.00% | 0.00% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 29 | 1729 | 11.58 | 462 | 440 | 111.3 |
| A | 7 | 110 | 1382 | 8.46 | 462 | 440 | 111.3 |
| A | 14 | 79 | 1302 | 7.74 | 462 | 440 | 111.3 |
| B | 2 | 9 | 1332 | 10.5 | 435 | 419 | 86.9 |
| B | 2 | 8 | 1127 | 8.14 | 435 | 419 | 86.9 |
| B | 5 | 255 | 1123 | 8.1 | 435 | 419 | 86.9 |
| C | 1 | 81 | 1412 | 8.39 | 458 | 436 | 116.4 |
| C | 1 | 80 | 1348 | 7.84 | 458 | 436 | 116.4 |
| C | 12 | 241 | 1260 | 7.08 | 458 | 436 | 116.4 |
| D | 10 | 189 | 1191 | 6.71 | 440 | 406 | 117.0 |
| D | 6 | 38 | 1116 | 6.07 | 440 | 406 | 117.0 |
| D | 6 | 67 | 1105 | 5.97 | 440 | 406 | 117.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
