| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_094T26_9000004558_31410cztM0_level2.evt | modeM0/AS1A10_094T26_9000004558_31410cztM0_level2_quad_clean.evt |
| Size (bytes) | 538,191,360 | 145,601,280 |
| Size | 513.3 MB | 138.9 MB |
| Events in quadrant A | 3,298,741 | 1,002,003 |
| Events in quadrant B | 4,992,095 | 1,006,297 |
| Events in quadrant C | 3,717,363 | 995,946 |
| Events in quadrant D | 3,869,527 | 971,530 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13605 | 2 |
| B | 0 | 19117 | 2 |
| C | 0 | 15149 | 2 |
| D | 0 | 15461 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16 | 0 |
| B | 0 | 17 | 0 |
| C | 0 | 17 | 0 |
| D | 0 | 17 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 128 | 0 |
| B | 0 | 128 | 0 |
| C | 0 | 128 | 0 |
| D | 0 | 128 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6220 | 16 | 0.257235% |
| B | 6219 | 65 | 1.045184% |
| C | 6219 | 164 | 2.637080% |
| D | 6219 | 39 | 0.627110% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7570 | 6221 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7569 | 6220 | 0 | 0 | 0.00% | 0.00% |  |
| C | 7569 | 6220 | 6 | 6 | 0.08% | 0.10% |  |
| D | 7569 | 6220 | 22 | 22 | 0.29% | 0.35% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 16 | 29710 | 174.6 | 846 | 830 | 165.4 |
| A | 12 | 194 | 10725 | 59.82 | 846 | 830 | 165.4 |
| A | 13 | 254 | 10150 | 56.34 | 846 | 830 | 165.4 |
| B | 6 | 159 | 1608593 | 10524.9 | 835 | 813 | 152.8 |
| B | 0 | 190 | 49226 | 316.92 | 835 | 813 | 152.8 |
| B | 4 | 80 | 38679 | 247.88 | 835 | 813 | 152.8 |
| C | 3 | 233 | 270960 | 1415.92 | 834 | 841 | 190.8 |
| C | 14 | 238 | 149841 | 781.03 | 834 | 841 | 190.8 |
| C | 14 | 254 | 18414 | 92.11 | 834 | 841 | 190.8 |
| D | 8 | 195 | 374025 | 1924.31 | 839 | 819 | 193.9 |
| D | 12 | 218 | 138163 | 708.17 | 839 | 819 | 193.9 |
| D | 12 | 233 | 127710 | 654.27 | 839 | 819 | 193.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
