| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_094T30_9000004566_31421cztM0_level2.evt | modeM0/AS1A10_094T30_9000004566_31421cztM0_level2_quad_clean.evt |
| Size (bytes) | 362,689,920 | 89,343,360 |
| Size | 345.9 MB | 85.2 MB |
| Events in quadrant A | 2,105,989 | 609,740 |
| Events in quadrant B | 3,404,857 | 607,312 |
| Events in quadrant C | 2,192,084 | 595,052 |
| Events in quadrant D | 2,979,627 | 581,813 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 11 | 0 |
| D | 0 | 11 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 9095 | 1 |
| B | 0 | 13444 | 1 |
| C | 0 | 9237 | 1 |
| D | 0 | 11841 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 92 | 0 |
| B | 0 | 92 | 0 |
| C | 0 | 92 | 0 |
| D | 0 | 92 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 4430 | 21 | 0.474041% |
| B | 4430 | 48 | 1.083521% |
| C | 4430 | 63 | 1.422122% |
| D | 4430 | 37 | 0.835214% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 5540 | 4430 | 0 | 0 | 0.00% | 0.00% |  |
| B | 5540 | 4431 | 0 | 0 | 0.00% | 0.00% |  |
| C | 5540 | 4431 | 0 | 0 | 0.00% | 0.00% |  |
| D | 5540 | 4430 | 12 | 12 | 0.22% | 0.27% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 7547 | 64.16 | 546 | 535 | 109.3 |
| A | 3 | 137 | 5542 | 45.82 | 546 | 535 | 109.3 |
| A | 0 | 226 | 4421 | 35.56 | 546 | 535 | 109.3 |
| B | 6 | 159 | 1232404 | 12047.69 | 536 | 524 | 102.3 |
| B | 4 | 80 | 35907 | 346.04 | 536 | 524 | 102.3 |
| B | 0 | 190 | 18833 | 179.06 | 536 | 524 | 102.3 |
| C | 14 | 238 | 96707 | 776.88 | 530 | 533 | 123.8 |
| C | 14 | 254 | 13528 | 104.97 | 530 | 533 | 123.8 |
| C | 2 | 114 | 10174 | 77.88 | 530 | 533 | 123.8 |
| D | 8 | 195 | 826663 | 6513.54 | 534 | 521 | 126.8 |
| D | 5 | 233 | 54161 | 422.91 | 534 | 521 | 126.8 |
| D | 2 | 250 | 26315 | 203.37 | 534 | 521 | 126.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
