| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_094T30_9000004566_31428cztM0_level2.evt | modeM0/AS1A10_094T30_9000004566_31428cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,356,039,360 | 272,926,080 |
| Size | 1.3 GB | 260.3 MB |
| Events in quadrant A | 6,591,150 | 1,971,514 |
| Events in quadrant B | 17,110,011 | 1,501,794 |
| Events in quadrant C | 6,902,665 | 1,959,291 |
| Events in quadrant D | 9,554,271 | 1,900,765 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 25 | 0 |
| B | 0 | 25 | 0 |
| C | 0 | 25 | 0 |
| D | 0 | 25 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 27758 | 2 |
| B | 0 | 60688 | 2 |
| C | 0 | 28583 | 2 |
| D | 0 | 37867 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 276 | 0 |
| B | 0 | 276 | 0 |
| C | 0 | 276 | 0 |
| D | 0 | 276 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 13480 | 87 | 0.645401% |
| B | 13481 | 4368 | 32.401157% |
| C | 13481 | 324 | 2.403383% |
| D | 13481 | 433 | 3.211928% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 16015 | 13482 | 0 | 0 | 0.00% | 0.00% |  |
| B | 16016 | 13481 | 3064 | 3064 | 19.13% | 22.73% |  |
| C | 16016 | 13483 | 5 | 5 | 0.03% | 0.04% |  |
| D | 16016 | 13483 | 323 | 323 | 2.02% | 2.40% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 25558 | 71.79 | 1703 | 1673 | 332.7 |
| A | 3 | 137 | 16219 | 43.72 | 1703 | 1673 | 332.7 |
| A | 12 | 16 | 15372 | 41.17 | 1703 | 1673 | 332.7 |
| B | 12 | 1 | 8883151 | 36929.26 | 1310 | 1278 | 240.5 |
| B | 6 | 159 | 2863145 | 11899.14 | 1310 | 1278 | 240.5 |
| B | 12 | 2 | 91670 | 375.83 | 1310 | 1278 | 240.5 |
| C | 14 | 238 | 312160 | 825.2 | 1648 | 1661 | 376.3 |
| C | 14 | 254 | 58996 | 152.38 | 1648 | 1661 | 376.3 |
| C | 3 | 233 | 52200 | 134.31 | 1648 | 1661 | 376.3 |
| D | 8 | 195 | 1249745 | 2951.21 | 1654 | 1626 | 422.9 |
| D | 12 | 218 | 1048798 | 2476.07 | 1654 | 1626 | 422.9 |
| D | 5 | 233 | 535475 | 1262.3 | 1654 | 1626 | 422.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
