| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_082T10_9000004602_31579cztM0_level2.evt | modeM0/AS1A10_082T10_9000004602_31579cztM0_level2_quad_clean.evt |
| Size (bytes) | 645,860,160 | 83,923,200 |
| Size | 615.9 MB | 80.0 MB |
| Events in quadrant A | 2,939,729 | 549,691 |
| Events in quadrant B | 5,584,002 | 538,738 |
| Events in quadrant C | 5,243,568 | 506,056 |
| Events in quadrant D | 5,370,775 | 510,379 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 8 | 0 |
| B | 0 | 8 | 0 |
| C | 0 | 8 | 0 |
| D | 0 | 8 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12857 | 1 |
| B | 0 | 20912 | 1 |
| C | 0 | 19723 | 1 |
| D | 0 | 20468 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 128 | 0 |
| B | 0 | 128 | 0 |
| C | 0 | 128 | 0 |
| D | 0 | 128 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6244 | 61 | 0.976938% |
| B | 6245 | 220 | 3.522818% |
| C | 6245 | 589 | 9.431545% |
| D | 6245 | 184 | 2.946357% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7124 | 6244 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7125 | 6245 | 99 | 99 | 1.39% | 1.59% |  |
| C | 7125 | 6245 | 275 | 275 | 3.86% | 4.40% |  |
| D | 7125 | 6245 | 102 | 102 | 1.43% | 1.63% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 12617 | 77.15 | 761 | 745 | 153.9 |
| A | 3 | 137 | 7826 | 46.02 | 761 | 745 | 153.9 |
| A | 0 | 226 | 6302 | 36.11 | 761 | 745 | 153.9 |
| B | 6 | 159 | 1754336 | 12194.16 | 748 | 729 | 143.8 |
| B | 12 | 1 | 527941 | 3666.1 | 748 | 729 | 143.8 |
| B | 4 | 80 | 259312 | 1798.12 | 748 | 729 | 143.8 |
| C | 3 | 233 | 2269820 | 13482.34 | 715 | 718 | 168.3 |
| C | 14 | 238 | 115982 | 684.87 | 715 | 718 | 168.3 |
| C | 4 | 175 | 38243 | 222.96 | 715 | 718 | 168.3 |
| D | 8 | 195 | 1963013 | 11164.3 | 732 | 710 | 175.8 |
| D | 2 | 250 | 290262 | 1647.37 | 732 | 710 | 175.8 |
| D | 12 | 233 | 99772 | 563.6 | 732 | 710 | 175.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
