| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_094T75_9000004614_31608cztM0_level2.evt | modeM0/AS1A10_094T75_9000004614_31608cztM0_level2_quad_clean.evt |
| Size (bytes) | 676,362,240 | 142,349,760 |
| Size | 645.0 MB | 135.8 MB |
| Events in quadrant A | 5,314,522 | 924,582 |
| Events in quadrant B | 5,965,003 | 974,889 |
| Events in quadrant C | 3,839,973 | 959,642 |
| Events in quadrant D | 4,850,473 | 923,750 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16 | 0 |
| B | 0 | 16 | 0 |
| C | 0 | 16 | 0 |
| D | 0 | 16 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 20835 | 2 |
| B | 0 | 23326 | 2 |
| C | 0 | 16286 | 2 |
| D | 0 | 19215 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 156 | 0 |
| B | 0 | 156 | 0 |
| C | 0 | 156 | 0 |
| D | 0 | 156 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7592 | 805 | 10.603267% |
| B | 7593 | 189 | 2.489135% |
| C | 7593 | 187 | 2.462795% |
| D | 7593 | 350 | 4.609509% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 9272 | 7594 | 478 | 478 | 5.16% | 6.29% |  |
| B | 9273 | 7595 | 43 | 43 | 0.46% | 0.57% |  |
| C | 9273 | 7595 | 28 | 28 | 0.30% | 0.37% |  |
| D | 9273 | 7595 | 264 | 264 | 2.85% | 3.48% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 13 | 1898567 | 10852.45 | 874 | 854 | 174.9 |
| A | 15 | 174 | 27550 | 152.67 | 874 | 854 | 174.9 |
| A | 13 | 254 | 13934 | 74.8 | 874 | 854 | 174.9 |
| B | 6 | 159 | 2099650 | 12153.04 | 905 | 881 | 172.7 |
| B | 0 | 229 | 128554 | 739.3 | 905 | 881 | 172.7 |
| B | 4 | 80 | 81944 | 469.4 | 905 | 881 | 172.7 |
| C | 14 | 238 | 145167 | 699.54 | 882 | 884 | 206.3 |
| C | 3 | 233 | 122724 | 590.72 | 882 | 884 | 206.3 |
| C | 12 | 175 | 58945 | 281.5 | 882 | 884 | 206.3 |
| D | 12 | 218 | 753849 | 3565.81 | 878 | 851 | 211.2 |
| D | 8 | 195 | 273740 | 1292.26 | 878 | 851 | 211.2 |
| D | 12 | 233 | 210363 | 992.14 | 878 | 851 | 211.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
