| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_123T01_9000004620_31626cztM0_level2.evt | modeM0/AS1A10_123T01_9000004620_31626cztM0_level2_quad_clean.evt |
| Size (bytes) | 651,208,320 | 83,554,560 |
| Size | 621.0 MB | 79.7 MB |
| Events in quadrant A | 2,951,669 | 570,455 |
| Events in quadrant B | 5,511,798 | 559,764 |
| Events in quadrant C | 4,063,547 | 523,309 |
| Events in quadrant D | 6,793,156 | 460,263 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12489 | 1 |
| B | 0 | 20589 | 1 |
| C | 0 | 15744 | 1 |
| D | 0 | 24514 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 120 | 0 |
| B | 0 | 120 | 0 |
| C | 0 | 120 | 0 |
| D | 0 | 120 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5956 | 34 | 0.570853% |
| B | 5957 | 280 | 4.700353% |
| C | 5957 | 346 | 5.808293% |
| D | 5957 | 770 | 12.925969% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7196 | 5957 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7197 | 5958 | 172 | 172 | 2.39% | 2.89% |  |
| C | 7197 | 5958 | 102 | 102 | 1.42% | 1.71% |  |
| D | 7197 | 5958 | 738 | 738 | 10.25% | 12.39% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 14 | 238 | 36535 | 237.98 | 752 | 738 | 150.4 |
| A | 13 | 254 | 12570 | 78.66 | 752 | 738 | 150.4 |
| A | 3 | 137 | 6969 | 41.42 | 752 | 738 | 150.4 |
| B | 6 | 159 | 1860396 | 13301.69 | 743 | 726 | 139.8 |
| B | 5 | 172 | 392862 | 2804.83 | 743 | 726 | 139.8 |
| B | 10 | 245 | 98459 | 699.05 | 743 | 726 | 139.8 |
| C | 3 | 233 | 898084 | 5431.05 | 709 | 717 | 165.2 |
| C | 14 | 238 | 150555 | 906.85 | 709 | 717 | 165.2 |
| C | 0 | 10 | 122166 | 735.03 | 709 | 717 | 165.2 |
| D | 8 | 195 | 1877319 | 11622.39 | 679 | 663 | 161.5 |
| D | 12 | 218 | 1193731 | 7388.84 | 679 | 663 | 161.5 |
| D | 11 | 176 | 525911 | 3252.93 | 679 | 663 | 161.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
