| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_123T01_9000004620_31630cztM0_level2.evt | modeM0/AS1A10_123T01_9000004620_31630cztM0_level2_quad_clean.evt |
| Size (bytes) | 674,498,880 | 60,180,480 |
| Size | 643.3 MB | 57.4 MB |
| Events in quadrant A | 3,073,957 | 390,470 |
| Events in quadrant B | 5,619,410 | 379,980 |
| Events in quadrant C | 4,381,063 | 327,685 |
| Events in quadrant D | 6,945,499 | 302,245 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13561 | 824 |
| B | 0 | 22254 | 1545 |
| C | 0 | 18055 | 1073 |
| D | 0 | 26740 | 1797 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 12 | 1 |
| D | 0 | 11 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 131 | 7 |
| B | 0 | 130 | 8 |
| C | 0 | 129 | 7 |
| D | 0 | 131 | 9 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6042 | 72 | 1.191658% |
| B | 6014 | 375 | 6.235451% |
| C | 6027 | 1443 | 23.942260% |
| D | 6015 | 839 | 13.948462% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7880 | 6074 | 4 | 4 | 0.05% | 0.07% |  |
| B | 7880 | 6040 | 159 | 159 | 2.02% | 2.63% |  |
| C | 7880 | 6063 | 49 | 49 | 0.62% | 0.81% |  |
| D | 7880 | 6050 | 743 | 743 | 9.43% | 12.28% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 96 | 37995 | 238.62 | 780 | 765 | 156.0 |
| A | 14 | 238 | 16872 | 103.23 | 780 | 765 | 156.0 |
| A | 13 | 254 | 11631 | 69.64 | 780 | 765 | 156.0 |
| B | 6 | 159 | 1783027 | 12418.73 | 762 | 744 | 143.5 |
| B | 10 | 245 | 502173 | 3493.9 | 762 | 744 | 143.5 |
| B | 5 | 172 | 192319 | 1334.87 | 762 | 744 | 143.5 |
| C | 3 | 233 | 779663 | 4974.07 | 665 | 669 | 156.6 |
| C | 14 | 254 | 424991 | 2709.4 | 665 | 669 | 156.6 |
| C | 14 | 238 | 415475 | 2648.64 | 665 | 669 | 156.6 |
| D | 8 | 195 | 2126852 | 12655.52 | 690 | 671 | 168.0 |
| D | 11 | 176 | 1047494 | 6230.93 | 690 | 671 | 168.0 |
| D | 12 | 218 | 739370 | 4396.91 | 690 | 671 | 168.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
