| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_103T09_9000004630_31681cztM0_level2.evt | modeM0/AS1A10_103T09_9000004630_31681cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,014,958,080 | 130,023,360 |
| Size | 967.9 MB | 124.0 MB |
| Events in quadrant A | 5,115,272 | 845,800 |
| Events in quadrant B | 11,373,654 | 757,544 |
| Events in quadrant C | 7,309,059 | 826,614 |
| Events in quadrant D | 6,253,840 | 802,288 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 24 | 1 |
| B | 0 | 24 | 1 |
| C | 0 | 24 | 1 |
| D | 0 | 23 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 21979 | 431 |
| B | 0 | 41441 | 677 |
| C | 0 | 28918 | 444 |
| D | 0 | 25662 | 518 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 209 | 3 |
| B | 0 | 210 | 6 |
| C | 0 | 211 | 7 |
| D | 0 | 209 | 5 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 10186 | 159 | 1.560966% |
| B | 10170 | 2132 | 20.963618% |
| C | 10187 | 784 | 7.696083% |
| D | 10184 | 218 | 2.140613% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 13970 | 10219 | 3 | 3 | 0.02% | 0.03% |  |
| B | 13970 | 10205 | 1505 | 1505 | 10.77% | 14.75% |  |
| C | 13970 | 10216 | 238 | 238 | 1.70% | 2.33% |  |
| D | 13970 | 10210 | 105 | 105 | 0.75% | 1.03% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 13 | 95342 | 361.55 | 1292 | 1265 | 260.2 |
| A | 12 | 96 | 18902 | 67.78 | 1292 | 1265 | 260.2 |
| A | 13 | 254 | 18739 | 67.16 | 1292 | 1265 | 260.2 |
| B | 4 | 80 | 3888890 | 17044.61 | 1185 | 1155 | 228.1 |
| B | 6 | 159 | 2516322 | 11027.0 | 1185 | 1155 | 228.1 |
| B | 0 | 229 | 110138 | 477.8 | 1185 | 1155 | 228.1 |
| C | 10 | 22 | 1117339 | 3938.92 | 1207 | 1212 | 283.4 |
| C | 3 | 233 | 866360 | 3053.19 | 1207 | 1212 | 283.4 |
| C | 0 | 10 | 366152 | 1287.91 | 1207 | 1212 | 283.4 |
| D | 8 | 195 | 809745 | 2720.15 | 1248 | 1215 | 297.2 |
| D | 13 | 249 | 345627 | 1158.71 | 1248 | 1215 | 297.2 |
| D | 10 | 203 | 282456 | 946.19 | 1248 | 1215 | 297.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
