| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_103T09_9000004630_31691cztM0_level2.evt | modeM0/AS1A10_103T09_9000004630_31691cztM0_level2_quad_clean.evt |
| Size (bytes) | 710,110,080 | 85,636,800 |
| Size | 677.2 MB | 81.7 MB |
| Events in quadrant A | 3,551,870 | 534,827 |
| Events in quadrant B | 5,780,267 | 534,442 |
| Events in quadrant C | 7,159,937 | 499,800 |
| Events in quadrant D | 4,510,298 | 504,997 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 1 | 0 |
| B | 0 | 1 | 0 |
| C | 0 | 1 | 0 |
| D | 0 | 1 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15554 | 15 |
| B | 0 | 22841 | 47 |
| C | 0 | 26579 | 113 |
| D | 0 | 18264 | 33 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 152 | 0 |
| B | 0 | 152 | 0 |
| C | 0 | 152 | 0 |
| D | 0 | 152 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7460 | 85 | 1.139410% |
| B | 7451 | 184 | 2.469467% |
| C | 7443 | 756 | 10.157195% |
| D | 7452 | 211 | 2.831455% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7639 | 7466 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7639 | 7464 | 4 | 4 | 0.05% | 0.05% |  |
| C | 7639 | 7469 | 141 | 141 | 1.85% | 1.89% |  |
| D | 7639 | 7465 | 103 | 103 | 1.35% | 1.38% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 13 | 48354 | 259.73 | 900 | 879 | 182.8 |
| A | 13 | 6 | 16216 | 83.91 | 900 | 879 | 182.8 |
| A | 13 | 254 | 14368 | 73.8 | 900 | 879 | 182.8 |
| B | 6 | 159 | 2088538 | 12090.02 | 892 | 870 | 172.7 |
| B | 0 | 229 | 46658 | 265.17 | 892 | 870 | 172.7 |
| B | 4 | 80 | 35188 | 198.74 | 892 | 870 | 172.7 |
| C | 3 | 233 | 3655680 | 18300.5 | 843 | 847 | 199.7 |
| C | 14 | 238 | 132268 | 658.05 | 843 | 847 | 199.7 |
| C | 0 | 10 | 48886 | 240.54 | 843 | 847 | 199.7 |
| D | 8 | 195 | 510122 | 2419.3 | 866 | 842 | 210.5 |
| D | 13 | 249 | 233612 | 1105.76 | 866 | 842 | 210.5 |
| D | 12 | 227 | 227919 | 1078.72 | 866 | 842 | 210.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
