| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T04_034T01_9000004632_31712cztM0_level2.evt | modeM0/AS1T04_034T01_9000004632_31712cztM0_level2_quad_clean.evt |
| Size (bytes) | 585,875,520 | 63,455,040 |
| Size | 558.7 MB | 60.5 MB |
| Events in quadrant A | 3,728,479 | 373,326 |
| Events in quadrant B | 5,944,531 | 375,244 |
| Events in quadrant C | 4,031,565 | 361,596 |
| Events in quadrant D | 3,601,720 | 360,673 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | 130 | 0 |
| D | 0 | 130 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15179 | 1 |
| B | 0 | 22042 | 1 |
| C | 0 | 16231 | 2 |
| D | 0 | 14883 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6459 | 146 | 2.260412% |
| B | 6459 | 512 | 7.926924% |
| C | 6458 | 200 | 3.096934% |
| D | 6459 | 41 | 0.634773% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7624 | 6460 | 84 | 84 | 1.10% | 1.30% |  |
| B | 7624 | 6460 | 252 | 252 | 3.31% | 3.90% |  |
| C | 7623 | 6459 | 64 | 64 | 0.84% | 0.99% |  |
| D | 7624 | 6460 | 10 | 10 | 0.13% | 0.15% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 13 | 351050 | 2000.88 | 872 | 856 | 175.0 |
| A | 13 | 254 | 12258 | 65.15 | 872 | 856 | 175.0 |
| A | 3 | 137 | 7973 | 40.66 | 872 | 856 | 175.0 |
| B | 6 | 159 | 1649128 | 10579.21 | 827 | 809 | 155.8 |
| B | 4 | 80 | 819344 | 5253.51 | 827 | 809 | 155.8 |
| B | 5 | 172 | 95233 | 606.03 | 827 | 809 | 155.8 |
| C | 0 | 10 | 576827 | 2984.7 | 825 | 833 | 193.0 |
| C | 14 | 238 | 134633 | 693.33 | 825 | 833 | 193.0 |
| C | 0 | 207 | 55577 | 283.67 | 825 | 833 | 193.0 |
| D | 8 | 195 | 293160 | 1449.84 | 852 | 833 | 201.6 |
| D | 2 | 250 | 56195 | 274.58 | 852 | 833 | 201.6 |
| D | 2 | 234 | 28169 | 135.58 | 852 | 833 | 201.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
