| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T04_034T01_9000004632_31715cztM0_level2.evt | modeM0/AS1T04_034T01_9000004632_31715cztM0_level2_quad_clean.evt |
| Size (bytes) | 724,717,440 | 91,984,320 |
| Size | 691.1 MB | 87.7 MB |
| Events in quadrant A | 5,935,051 | 568,644 |
| Events in quadrant B | 5,625,854 | 611,772 |
| Events in quadrant C | 5,002,359 | 595,718 |
| Events in quadrant D | 4,975,100 | 584,892 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 25 | 0 |
| B | 0 | 26 | 0 |
| C | 0 | 26 | 0 |
| D | 0 | 26 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 122 | 0 |
| B | 0 | 122 | 0 |
| C | 0 | 122 | 0 |
| D | 0 | 122 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 21743 | 2 |
| B | 0 | 20840 | 2 |
| C | 0 | 19211 | 2 |
| D | 0 | 18834 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6086 | 1062 | 17.449885% |
| B | 6086 | 296 | 4.863621% |
| C | 6086 | 449 | 7.377588% |
| D | 6086 | 517 | 8.494906% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7461 | 6087 | 679 | 679 | 9.10% | 11.15% |  |
| B | 7461 | 6087 | 46 | 46 | 0.62% | 0.76% |  |
| C | 7461 | 6087 | 141 | 141 | 1.89% | 2.32% |  |
| D | 7461 | 6087 | 335 | 335 | 4.49% | 5.50% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 13 | 1820114 | 11077.0 | 826 | 813 | 164.2 |
| A | 12 | 96 | 923955 | 5620.65 | 826 | 813 | 164.2 |
| A | 13 | 254 | 11435 | 64.67 | 826 | 813 | 164.2 |
| B | 6 | 159 | 1744815 | 10579.31 | 891 | 871 | 164.8 |
| B | 0 | 229 | 125071 | 753.44 | 891 | 871 | 164.8 |
| B | 4 | 80 | 120107 | 723.32 | 891 | 871 | 164.8 |
| C | 0 | 10 | 1102101 | 5638.38 | 855 | 867 | 195.3 |
| C | 10 | 22 | 215631 | 1099.6 | 855 | 867 | 195.3 |
| C | 14 | 238 | 139809 | 711.39 | 855 | 867 | 195.3 |
| D | 12 | 233 | 935637 | 4597.94 | 867 | 850 | 203.3 |
| D | 8 | 195 | 467013 | 2292.92 | 867 | 850 | 203.3 |
| D | 13 | 249 | 263051 | 1289.69 | 867 | 850 | 203.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
