| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_059T01_9000004634_31757cztM0_level2.evt | modeM0/AS1A10_059T01_9000004634_31757cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,938,234,240 | 279,074,880 |
| Size | 1.8 GB | 266.1 MB |
| Events in quadrant A | 16,591,067 | 1,758,378 |
| Events in quadrant B | 15,399,260 | 1,903,241 |
| Events in quadrant C | 11,228,463 | 1,854,231 |
| Events in quadrant D | 14,359,359 | 1,782,983 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 35 | 0 |
| B | 0 | 35 | 0 |
| C | 0 | 35 | 0 |
| D | 0 | 35 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 342 | 0 |
| B | 0 | 342 | 0 |
| C | 0 | 342 | 0 |
| D | 0 | 342 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 60855 | 4 |
| B | 0 | 57151 | 4 |
| C | 0 | 44529 | 4 |
| D | 0 | 53884 | 4 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 16710 | 3335 | 19.958109% |
| B | 16710 | 1130 | 6.762418% |
| C | 16710 | 906 | 5.421903% |
| D | 16710 | 1181 | 7.067624% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 20285 | 16711 | 1966 | 1966 | 9.69% | 11.76% |  |
| B | 20285 | 16713 | 626 | 626 | 3.09% | 3.75% |  |
| C | 20285 | 16713 | 271 | 271 | 1.34% | 1.62% |  |
| D | 20285 | 16713 | 734 | 734 | 3.62% | 4.39% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 13 | 8963458 | 22876.17 | 1978 | 1949 | 391.7 |
| A | 13 | 254 | 28580 | 67.98 | 1978 | 1949 | 391.7 |
| A | 3 | 137 | 18238 | 41.58 | 1978 | 1949 | 391.7 |
| B | 6 | 159 | 4517488 | 11447.9 | 2131 | 2082 | 394.4 |
| B | 10 | 245 | 1232443 | 3119.33 | 2131 | 2082 | 394.4 |
| B | 5 | 172 | 881864 | 2230.51 | 2131 | 2082 | 394.4 |
| C | 0 | 10 | 1979235 | 4239.64 | 2043 | 2062 | 466.4 |
| C | 3 | 233 | 855618 | 1830.27 | 2043 | 2062 | 466.4 |
| C | 14 | 238 | 334954 | 713.82 | 2043 | 2062 | 466.4 |
| D | 8 | 195 | 3427036 | 7052.74 | 2071 | 2025 | 485.6 |
| D | 12 | 218 | 1808213 | 3719.28 | 2071 | 2025 | 485.6 |
| D | 12 | 233 | 414008 | 848.35 | 2071 | 2025 | 485.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
