| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T04_041T01_9000004642_31804cztM0_level2.evt | modeM0/AS1T04_041T01_9000004642_31804cztM0_level2_quad_clean.evt |
| Size (bytes) | 614,041,920 | 103,867,200 |
| Size | 585.6 MB | 99.1 MB |
| Events in quadrant A | 4,139,974 | 681,270 |
| Events in quadrant B | 5,026,627 | 697,535 |
| Events in quadrant C | 4,241,774 | 666,497 |
| Events in quadrant D | 4,754,137 | 652,436 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 11 | 0 |
| D | 0 | 11 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16355 | 1 |
| B | 0 | 19633 | 1 |
| C | 0 | 16918 | 1 |
| D | 0 | 18685 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | 130 | 0 |
| D | 0 | 130 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6421 | 231 | 3.597570% |
| B | 6420 | 130 | 2.024922% |
| C | 6420 | 332 | 5.171340% |
| D | 6420 | 75 | 1.168224% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7481 | 6422 | 152 | 152 | 2.03% | 2.37% |  |
| B | 7480 | 6421 | 1 | 1 | 0.01% | 0.02% |  |
| C | 7480 | 6421 | 68 | 68 | 0.91% | 1.06% |  |
| D | 7480 | 6421 | 23 | 23 | 0.31% | 0.36% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 13 | 942621 | 5690.58 | 827 | 813 | 165.5 |
| A | 13 | 254 | 10793 | 60.3 | 827 | 813 | 165.5 |
| A | 3 | 137 | 8039 | 43.66 | 827 | 813 | 165.5 |
| B | 6 | 159 | 1703285 | 10865.34 | 822 | 803 | 156.7 |
| B | 0 | 229 | 33409 | 208.09 | 822 | 803 | 156.7 |
| B | 10 | 245 | 31905 | 198.49 | 822 | 803 | 156.7 |
| C | 3 | 233 | 711130 | 3808.26 | 800 | 809 | 186.5 |
| C | 0 | 10 | 213938 | 1142.65 | 800 | 809 | 186.5 |
| C | 14 | 238 | 143972 | 767.54 | 800 | 809 | 186.5 |
| D | 8 | 195 | 1436171 | 7462.79 | 816 | 797 | 192.3 |
| D | 12 | 233 | 73525 | 378.13 | 816 | 797 | 192.3 |
| D | 2 | 250 | 71987 | 370.13 | 816 | 797 | 192.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
