| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_123T09_9000004654_31907cztM0_level2.evt | modeM0/AS1A10_123T09_9000004654_31907cztM0_level2_quad_clean.evt |
| Size (bytes) | 936,282,240 | 90,771,840 |
| Size | 892.9 MB | 86.6 MB |
| Events in quadrant A | 3,233,424 | 663,437 |
| Events in quadrant B | 7,220,612 | 602,371 |
| Events in quadrant C | 4,111,576 | 621,234 |
| Events in quadrant D | 13,330,331 | 384,348 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14062 | 1 |
| B | 0 | 26302 | 1 |
| C | 0 | 16587 | 1 |
| D | 0 | 44304 | 5 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 140 | 0 |
| B | 0 | 140 | 0 |
| C | 0 | 140 | 0 |
| D | 0 | 140 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 4 | 0 |
| B | 0 | 4 | 0 |
| C | 0 | 4 | 0 |
| D | 0 | 4 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6814 | 37 | 0.543000% |
| B | 6815 | 855 | 12.545855% |
| C | 6815 | 215 | 3.154806% |
| D | 6814 | 4254 | 62.430291% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7229 | 6815 | 3 | 3 | 0.04% | 0.04% |  |
| B | 7230 | 6816 | 582 | 582 | 8.05% | 8.54% |  |
| C | 7230 | 6816 | 41 | 41 | 0.57% | 0.60% |  |
| D | 7229 | 6815 | 4208 | 4208 | 58.21% | 61.75% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 174 | 14701 | 83.97 | 829 | 811 | 165.4 |
| A | 13 | 254 | 14330 | 81.72 | 829 | 811 | 165.4 |
| A | 13 | 6 | 8585 | 46.99 | 829 | 811 | 165.4 |
| B | 6 | 159 | 1983348 | 13303.31 | 784 | 764 | 149.0 |
| B | 4 | 80 | 890761 | 5971.96 | 784 | 764 | 149.0 |
| B | 5 | 172 | 660829 | 4429.09 | 784 | 764 | 149.0 |
| C | 0 | 10 | 468371 | 2526.5 | 790 | 794 | 185.1 |
| C | 3 | 233 | 352566 | 1900.76 | 790 | 794 | 185.1 |
| C | 14 | 238 | 128038 | 687.55 | 790 | 794 | 185.1 |
| D | 12 | 33 | 9474509 | 66395.74 | 597 | 581 | 142.7 |
| D | 8 | 195 | 817245 | 5723.39 | 597 | 581 | 142.7 |
| D | 7 | 38 | 167522 | 1169.97 | 597 | 581 | 142.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
