| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_053T11_9000004668_31969cztM0_level2.evt | modeM0/AS1A10_053T11_9000004668_31969cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,114,819,200 | 176,129,280 |
| Size | 1.0 GB | 168.0 MB |
| Events in quadrant A | 6,051,355 | 1,135,832 |
| Events in quadrant B | 9,853,162 | 1,127,425 |
| Events in quadrant C | 7,801,050 | 1,097,140 |
| Events in quadrant D | 9,179,529 | 1,074,885 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 17 | 0 |
| B | 0 | 17 | 0 |
| C | 0 | 17 | 0 |
| D | 0 | 17 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 26627 | 3 |
| B | 0 | 39586 | 4 |
| C | 0 | 31377 | 3 |
| D | 0 | 36088 | 3 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 270 | 0 |
| B | 0 | 270 | 0 |
| C | 0 | 270 | 0 |
| D | 0 | 270 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 12998 | 54 | 0.415449% |
| B | 12997 | 233 | 1.792721% |
| C | 12998 | 398 | 3.062010% |
| D | 12998 | 308 | 2.369595% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 14808 | 13000 | 1 | 1 | 0.01% | 0.01% |  |
| B | 14807 | 12997 | 38 | 38 | 0.26% | 0.29% |  |
| C | 14808 | 12999 | 68 | 68 | 0.46% | 0.52% |  |
| D | 14808 | 12999 | 241 | 241 | 1.63% | 1.85% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 23726 | 70.38 | 1565 | 1530 | 315.4 |
| A | 3 | 137 | 16904 | 48.75 | 1565 | 1530 | 315.4 |
| A | 0 | 226 | 13136 | 36.8 | 1565 | 1530 | 315.4 |
| B | 6 | 159 | 3451960 | 11561.36 | 1548 | 1501 | 298.4 |
| B | 10 | 245 | 207219 | 689.29 | 1548 | 1501 | 298.4 |
| B | 12 | 111 | 37769 | 121.52 | 1548 | 1501 | 298.4 |
| C | 0 | 10 | 1064805 | 3021.06 | 1494 | 1499 | 352.0 |
| C | 3 | 233 | 608026 | 1723.26 | 1494 | 1499 | 352.0 |
| C | 14 | 238 | 249155 | 703.64 | 1494 | 1499 | 352.0 |
| D | 8 | 195 | 1557542 | 4310.88 | 1507 | 1463 | 361.0 |
| D | 7 | 238 | 1547430 | 4282.86 | 1507 | 1463 | 361.0 |
| D | 2 | 250 | 160458 | 440.47 | 1507 | 1463 | 361.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
