| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_058T12_9000004674_31984cztM0_level2.evt | modeM0/AS1A10_058T12_9000004674_31984cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,569,873,600 | 237,003,840 |
| Size | 1.5 GB | 226.0 MB |
| Events in quadrant A | 8,691,088 | 1,526,036 |
| Events in quadrant B | 14,214,537 | 1,514,799 |
| Events in quadrant C | 10,834,981 | 1,462,622 |
| Events in quadrant D | 12,563,164 | 1,406,495 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 376 | 0 |
| B | 0 | 376 | 0 |
| C | 0 | 376 | 0 |
| D | 0 | 376 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 37895 | 4 |
| B | 0 | 56303 | 4 |
| C | 0 | 43938 | 4 |
| D | 0 | 49885 | 4 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 20 | 0 |
| B | 0 | 20 | 0 |
| C | 0 | 20 | 0 |
| D | 0 | 20 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 18393 | 74 | 0.402327% |
| B | 18394 | 342 | 1.859302% |
| C | 18394 | 977 | 5.311515% |
| D | 18394 | 1013 | 5.507231% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 20428 | 18394 | 0 | 0 | 0.00% | 0.00% |  |
| B | 20429 | 18394 | 41 | 41 | 0.20% | 0.22% |  |
| C | 20429 | 18394 | 457 | 457 | 2.24% | 2.48% |  |
| D | 20429 | 18394 | 837 | 837 | 4.10% | 4.55% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 35273 | 73.49 | 2247 | 2196 | 450.1 |
| A | 3 | 137 | 23341 | 46.98 | 2247 | 2196 | 450.1 |
| A | 0 | 226 | 18743 | 36.76 | 2247 | 2196 | 450.1 |
| B | 6 | 159 | 4875791 | 11393.31 | 2219 | 2164 | 427.8 |
| B | 10 | 245 | 181224 | 418.6 | 2219 | 2164 | 427.8 |
| B | 0 | 198 | 122981 | 282.44 | 2219 | 2164 | 427.8 |
| C | 0 | 10 | 1204641 | 2422.24 | 2111 | 2123 | 496.4 |
| C | 3 | 233 | 687436 | 1380.43 | 2111 | 2123 | 496.4 |
| C | 14 | 238 | 417873 | 837.45 | 2111 | 2123 | 496.4 |
| D | 2 | 250 | 1912089 | 3735.68 | 2125 | 2066 | 511.3 |
| D | 8 | 195 | 1010317 | 1971.97 | 2125 | 2066 | 511.3 |
| D | 13 | 249 | 601299 | 1172.0 | 2125 | 2066 | 511.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
