| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_058T12_9000004674_31991cztM0_level2.evt | modeM0/AS1A10_058T12_9000004674_31991cztM0_level2_quad_clean.evt |
| Size (bytes) | 552,441,600 | 66,631,680 |
| Size | 526.8 MB | 63.5 MB |
| Events in quadrant A | 3,344,774 | 413,125 |
| Events in quadrant B | 4,986,729 | 402,639 |
| Events in quadrant C | 3,940,632 | 382,902 |
| Events in quadrant D | 4,041,390 | 388,294 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 126 | 0 |
| B | 0 | 126 | 0 |
| C | 0 | 126 | 0 |
| D | 0 | 126 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13334 | 2 |
| B | 0 | 18875 | 4 |
| C | 0 | 15895 | 2 |
| D | 0 | 16029 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6162 | 102 | 1.655307% |
| B | 6162 | 179 | 2.904901% |
| C | 6162 | 184 | 2.986043% |
| D | 6162 | 137 | 2.223304% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7387 | 6162 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7387 | 6162 | 7 | 7 | 0.09% | 0.11% |  |
| C | 7387 | 6163 | 11 | 11 | 0.15% | 0.18% |  |
| D | 7387 | 6163 | 60 | 60 | 0.81% | 0.97% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 6 | 16773 | 93.36 | 863 | 848 | 170.6 |
| A | 13 | 254 | 11515 | 62.54 | 863 | 848 | 170.6 |
| A | 3 | 137 | 8217 | 43.2 | 863 | 848 | 170.6 |
| B | 6 | 159 | 1577659 | 10031.29 | 834 | 816 | 157.2 |
| B | 0 | 190 | 85758 | 540.37 | 834 | 816 | 157.2 |
| B | 12 | 111 | 19225 | 117.11 | 834 | 816 | 157.2 |
| C | 3 | 233 | 529724 | 2825.1 | 804 | 810 | 187.2 |
| C | 14 | 238 | 135517 | 719.51 | 804 | 810 | 187.2 |
| C | 10 | 22 | 49964 | 262.55 | 804 | 810 | 187.2 |
| D | 8 | 195 | 589912 | 3014.93 | 829 | 810 | 195.4 |
| D | 12 | 233 | 192993 | 983.56 | 829 | 810 | 195.4 |
| D | 2 | 250 | 55112 | 277.91 | 829 | 810 | 195.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
