| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_109T01_9000004682_32063cztM0_level2.evt | modeM0/AS1A10_109T01_9000004682_32063cztM0_level2_quad_clean.evt |
| Size (bytes) | 667,275,840 | 75,824,640 |
| Size | 636.4 MB | 72.3 MB |
| Events in quadrant A | 3,586,063 | 491,243 |
| Events in quadrant B | 5,365,300 | 486,077 |
| Events in quadrant C | 4,323,197 | 452,409 |
| Events in quadrant D | 6,505,379 | 422,590 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 20 | 0 |
| B | 0 | 21 | 0 |
| C | 0 | 21 | 0 |
| D | 0 | 21 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14197 | 1 |
| B | 0 | 19934 | 1 |
| C | 0 | 16923 | 1 |
| D | 0 | 23961 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 128 | 0 |
| B | 0 | 128 | 0 |
| C | 0 | 128 | 0 |
| D | 0 | 128 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6359 | 87 | 1.368140% |
| B | 6359 | 166 | 2.610473% |
| C | 6359 | 350 | 5.504010% |
| D | 6358 | 398 | 6.259830% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7679 | 6359 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7679 | 6359 | 0 | 0 | 0.00% | 0.00% |  |
| C | 7679 | 6359 | 95 | 95 | 1.24% | 1.49% |  |
| D | 7678 | 6358 | 323 | 323 | 4.21% | 5.08% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 254 | 11425 | 57.61 | 929 | 917 | 182.4 |
| A | 3 | 137 | 8273 | 40.33 | 929 | 917 | 182.4 |
| A | 0 | 226 | 7865 | 38.09 | 929 | 917 | 182.4 |
| B | 6 | 159 | 1635509 | 9650.4 | 912 | 893 | 169.4 |
| B | 10 | 245 | 105542 | 617.82 | 912 | 893 | 169.4 |
| B | 0 | 190 | 31950 | 183.35 | 912 | 893 | 169.4 |
| C | 0 | 10 | 660377 | 3351.96 | 853 | 863 | 196.8 |
| C | 14 | 238 | 163372 | 825.95 | 853 | 863 | 196.8 |
| C | 12 | 249 | 48975 | 244.53 | 853 | 863 | 196.8 |
| D | 8 | 195 | 2224730 | 10893.69 | 863 | 843 | 204.1 |
| D | 12 | 227 | 789789 | 3864.64 | 863 | 843 | 204.1 |
| D | 12 | 218 | 172078 | 838.79 | 863 | 843 | 204.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
