| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T04_051T01_9000004686_32099cztM0_level2.evt | modeM0/AS1T04_051T01_9000004686_32099cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,389,795,840 | 167,469,120 |
| Size | 1.3 GB | 159.7 MB |
| Events in quadrant A | 5,487,745 | 1,147,528 |
| Events in quadrant B | 10,838,137 | 1,093,000 |
| Events in quadrant C | 7,902,938 | 1,055,490 |
| Events in quadrant D | 17,081,908 | 972,239 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 14 | 1 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 25527 | 1753 |
| B | 0 | 43168 | 3000 |
| C | 0 | 32844 | 1950 |
| D | 0 | 62232 | 3326 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 256 | 22 |
| B | 0 | 250 | 16 |
| C | 0 | 256 | 24 |
| D | 0 | 253 | 17 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 11659 | 26 | 0.223004% |
| B | 11539 | 717 | 6.213710% |
| C | 11645 | 1361 | 11.687419% |
| D | 11567 | 3030 | 26.195211% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 19334 | 11823 | 0 | 0 | 0.00% | 0.00% |  |
| B | 19335 | 11705 | 494 | 494 | 2.55% | 4.22% |  |
| C | 19335 | 11813 | 523 | 523 | 2.70% | 4.43% |  |
| D | 19334 | 11722 | 3168 | 3168 | 16.39% | 27.03% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 6 | 25166 | 84.38 | 1410 | 1382 | 281.9 |
| A | 13 | 254 | 23479 | 78.4 | 1410 | 1382 | 281.9 |
| A | 15 | 174 | 15911 | 51.55 | 1410 | 1382 | 281.9 |
| B | 6 | 159 | 3332310 | 13015.99 | 1350 | 1317 | 255.9 |
| B | 10 | 245 | 1131300 | 4415.45 | 1350 | 1317 | 255.9 |
| B | 12 | 18 | 414462 | 1614.38 | 1350 | 1317 | 255.9 |
| C | 0 | 10 | 2099172 | 6996.92 | 1279 | 1286 | 299.8 |
| C | 14 | 238 | 420550 | 1398.34 | 1279 | 1286 | 299.8 |
| C | 14 | 254 | 297074 | 986.52 | 1279 | 1286 | 299.8 |
| D | 12 | 79 | 6294982 | 20830.19 | 1257 | 1221 | 302.1 |
| D | 8 | 195 | 4188045 | 13856.95 | 1257 | 1221 | 302.1 |
| D | 12 | 218 | 1010775 | 3341.28 | 1257 | 1221 | 302.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
