| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T04_051T01_9000004686_32121cztM0_level2.evt | modeM0/AS1T04_051T01_9000004686_32121cztM0_level2_quad_clean.evt |
| Size (bytes) | 644,016,960 | 78,252,480 |
| Size | 614.2 MB | 74.6 MB |
| Events in quadrant A | 3,239,880 | 521,433 |
| Events in quadrant B | 5,876,929 | 503,246 |
| Events in quadrant C | 3,502,135 | 519,679 |
| Events in quadrant D | 6,482,678 | 408,421 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14 | 0 |
| B | 0 | 14 | 0 |
| C | 0 | 14 | 0 |
| D | 0 | 14 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12945 | 1 |
| B | 0 | 21268 | 1 |
| C | 0 | 14092 | 1 |
| D | 0 | 23367 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 122 | 0 |
| B | 0 | 122 | 0 |
| C | 0 | 122 | 0 |
| D | 0 | 122 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5955 | 19 | 0.319060% |
| B | 5956 | 341 | 5.725319% |
| C | 5956 | 149 | 2.501679% |
| D | 5956 | 1233 | 20.701813% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7370 | 5956 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7371 | 5957 | 136 | 136 | 1.85% | 2.28% |  |
| C | 7371 | 5957 | 33 | 33 | 0.45% | 0.55% |  |
| D | 7371 | 5957 | 1252 | 1252 | 16.99% | 21.02% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 6 | 13842 | 79.67 | 836 | 827 | 163.4 |
| A | 13 | 254 | 11219 | 63.62 | 836 | 827 | 163.4 |
| A | 3 | 137 | 7306 | 39.66 | 836 | 827 | 163.4 |
| B | 6 | 159 | 1569370 | 10541.55 | 812 | 794 | 148.8 |
| B | 10 | 245 | 658651 | 4421.1 | 812 | 794 | 148.8 |
| B | 12 | 18 | 303880 | 2036.88 | 812 | 794 | 148.8 |
| C | 0 | 10 | 168115 | 911.43 | 808 | 815 | 183.6 |
| C | 14 | 238 | 142329 | 770.95 | 808 | 815 | 183.6 |
| C | 2 | 114 | 13530 | 69.27 | 808 | 815 | 183.6 |
| D | 12 | 233 | 2989229 | 17332.09 | 746 | 729 | 172.4 |
| D | 8 | 195 | 632533 | 3664.21 | 746 | 729 | 172.4 |
| D | 2 | 234 | 23056 | 129.49 | 746 | 729 | 172.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
