| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T04_051T01_9000004686_32122cztM0_level2.evt | modeM0/AS1T04_051T01_9000004686_32122cztM0_level2_quad_clean.evt |
| Size (bytes) | 589,178,880 | 98,936,640 |
| Size | 561.9 MB | 94.4 MB |
| Events in quadrant A | 3,342,926 | 652,863 |
| Events in quadrant B | 6,031,482 | 631,165 |
| Events in quadrant C | 3,710,635 | 645,391 |
| Events in quadrant D | 4,330,014 | 624,868 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 11 | 0 |
| D | 0 | 11 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13410 | 1 |
| B | 0 | 22033 | 1 |
| C | 0 | 14768 | 2 |
| D | 0 | 17228 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | 130 | 0 |
| D | 0 | 130 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6327 | 124 | 1.959855% |
| B | 6328 | 453 | 7.158660% |
| C | 6327 | 272 | 4.299036% |
| D | 6328 | 164 | 2.591656% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7447 | 6328 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7448 | 6329 | 128 | 128 | 1.72% | 2.02% |  |
| C | 7448 | 6329 | 44 | 44 | 0.59% | 0.70% |  |
| D | 7448 | 6329 | 43 | 43 | 0.58% | 0.68% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 6 | 13846 | 76.95 | 863 | 848 | 168.9 |
| A | 13 | 254 | 11990 | 65.97 | 863 | 848 | 168.9 |
| A | 3 | 137 | 7981 | 42.23 | 863 | 848 | 168.9 |
| B | 6 | 159 | 1660835 | 10624.61 | 837 | 819 | 156.2 |
| B | 12 | 18 | 461590 | 2949.07 | 837 | 819 | 156.2 |
| B | 10 | 245 | 418416 | 2672.75 | 837 | 819 | 156.2 |
| C | 0 | 10 | 305514 | 1608.13 | 826 | 833 | 189.5 |
| C | 14 | 238 | 142172 | 746.0 | 826 | 833 | 189.5 |
| C | 2 | 114 | 14579 | 72.55 | 826 | 833 | 189.5 |
| D | 8 | 195 | 908081 | 4655.92 | 841 | 820 | 194.9 |
| D | 12 | 233 | 193608 | 989.36 | 841 | 820 | 194.9 |
| D | 2 | 234 | 29105 | 145.15 | 841 | 820 | 194.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
