| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T04_051T01_9000004686_32134cztM0_level2.evt | modeM0/AS1T04_051T01_9000004686_32134cztM0_level2_quad_clean.evt |
| Size (bytes) | 738,889,920 | 70,539,840 |
| Size | 704.7 MB | 67.3 MB |
| Events in quadrant A | 3,451,865 | 452,192 |
| Events in quadrant B | 8,933,802 | 392,844 |
| Events in quadrant C | 4,134,872 | 432,032 |
| Events in quadrant D | 5,433,135 | 419,747 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18 | 0 |
| B | 0 | 19 | 0 |
| C | 0 | 19 | 0 |
| D | 0 | 19 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13874 | 2 |
| B | 0 | 30809 | 2 |
| C | 0 | 16190 | 2 |
| D | 0 | 20700 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 126 | 0 |
| B | 0 | 126 | 0 |
| C | 0 | 126 | 0 |
| D | 0 | 126 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6280 | 36 | 0.573248% |
| B | 6280 | 1912 | 30.445860% |
| C | 6280 | 332 | 5.286624% |
| D | 6280 | 225 | 3.582803% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7645 | 6281 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7645 | 6281 | 1480 | 1480 | 19.36% | 23.56% |  |
| C | 7645 | 6281 | 146 | 146 | 1.91% | 2.32% |  |
| D | 7645 | 6281 | 145 | 145 | 1.90% | 2.31% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 6 | 20578 | 113.44 | 888 | 874 | 173.7 |
| A | 13 | 254 | 11364 | 60.4 | 888 | 874 | 173.7 |
| A | 3 | 137 | 7919 | 40.56 | 888 | 874 | 173.7 |
| B | 10 | 245 | 3996342 | 26971.35 | 805 | 789 | 148.1 |
| B | 6 | 159 | 1551296 | 10466.45 | 805 | 789 | 148.1 |
| B | 5 | 172 | 114285 | 766.14 | 805 | 789 | 148.1 |
| C | 0 | 10 | 604131 | 3108.2 | 850 | 858 | 194.1 |
| C | 14 | 238 | 150650 | 771.76 | 850 | 858 | 194.1 |
| C | 10 | 91 | 17524 | 85.87 | 850 | 858 | 194.1 |
| D | 8 | 195 | 1632579 | 8203.91 | 855 | 835 | 198.9 |
| D | 12 | 233 | 273562 | 1371.19 | 855 | 835 | 198.9 |
| D | 12 | 227 | 160162 | 801.05 | 855 | 835 | 198.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
