| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T04_051T01_9000004686_32136cztM0_level2.evt | modeM0/AS1T04_051T01_9000004686_32136cztM0_level2_quad_clean.evt |
| Size (bytes) | 690,307,200 | 83,113,920 |
| Size | 658.3 MB | 79.3 MB |
| Events in quadrant A | 3,416,212 | 553,224 |
| Events in quadrant B | 8,235,850 | 450,832 |
| Events in quadrant C | 3,774,698 | 547,473 |
| Events in quadrant D | 5,054,683 | 525,981 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 19 | 0 |
| B | 0 | 19 | 0 |
| C | 0 | 20 | 0 |
| D | 0 | 20 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13680 | 2 |
| B | 0 | 28685 | 2 |
| C | 0 | 15043 | 2 |
| D | 0 | 19689 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 128 | 0 |
| B | 0 | 128 | 0 |
| C | 0 | 128 | 0 |
| D | 0 | 128 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6285 | 72 | 1.145585% |
| B | 6285 | 1676 | 26.666667% |
| C | 6285 | 262 | 4.168656% |
| D | 6285 | 136 | 2.163882% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7585 | 6286 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7585 | 6286 | 1262 | 1262 | 16.64% | 20.08% |  |
| C | 7585 | 6286 | 28 | 28 | 0.37% | 0.45% |  |
| D | 7585 | 6286 | 78 | 78 | 1.03% | 1.24% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 6 | 17615 | 96.38 | 881 | 867 | 173.8 |
| A | 13 | 254 | 12063 | 64.43 | 881 | 867 | 173.8 |
| A | 3 | 137 | 8024 | 41.19 | 881 | 867 | 173.8 |
| B | 10 | 245 | 2335224 | 16254.02 | 779 | 762 | 143.6 |
| B | 6 | 159 | 1509640 | 10505.78 | 779 | 762 | 143.6 |
| B | 5 | 172 | 1273858 | 8864.11 | 779 | 762 | 143.6 |
| C | 0 | 10 | 247152 | 1273.86 | 846 | 856 | 193.3 |
| C | 14 | 238 | 149353 | 768.04 | 846 | 856 | 193.3 |
| C | 4 | 175 | 43122 | 218.6 | 846 | 856 | 193.3 |
| D | 8 | 195 | 1504758 | 7558.74 | 857 | 835 | 199.0 |
| D | 14 | 52 | 177721 | 889.03 | 857 | 835 | 199.0 |
| D | 12 | 233 | 84903 | 422.53 | 857 | 835 | 199.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
