| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A09_131T01_9000004690_32154cztM0_level2.evt | modeM0/AS1A09_131T01_9000004690_32154cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,097,832,960 | 89,922,240 |
| Size | 1.0 GB | 85.8 MB |
| Events in quadrant A | 5,702,712 | 500,852 |
| Events in quadrant B | 11,758,822 | 462,150 |
| Events in quadrant C | 8,065,733 | 478,358 |
| Events in quadrant D | 6,939,816 | 480,342 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 278 | 38 |
| B | 0 | 275 | 45 |
| C | 0 | 274 | 31 |
| D | 0 | 277 | 45 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 28454 | 4087 |
| B | 0 | 51571 | 8488 |
| C | 0 | 36995 | 5695 |
| D | 0 | 32277 | 4398 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 6 | 3 |
| B | 0 | 4 | 1 |
| C | 0 | 5 | 2 |
| D | 0 | 6 | 3 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 11675 | 336 | 2.877944% |
| B | 11355 | 1615 | 14.222809% |
| C | 11583 | 883 | 7.623241% |
| D | 11640 | 267 | 2.293814% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 14168 | 12083 | 0 | 0 | 0.00% | 0.00% |  |
| B | 14168 | 11750 | 866 | 866 | 6.11% | 7.37% |  |
| C | 14168 | 11971 | 175 | 175 | 1.24% | 1.46% |  |
| D | 14168 | 12040 | 62 | 62 | 0.44% | 0.51% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 189 | 92072 | 314.8 | 1446 | 1410 | 288.0 |
| A | 13 | 6 | 22216 | 72.24 | 1446 | 1410 | 288.0 |
| A | 13 | 254 | 20109 | 64.93 | 1446 | 1410 | 288.0 |
| B | 6 | 159 | 2985556 | 11751.17 | 1345 | 1309 | 254.0 |
| B | 10 | 245 | 2681925 | 10555.55 | 1345 | 1309 | 254.0 |
| B | 5 | 172 | 412293 | 1618.35 | 1345 | 1309 | 254.0 |
| C | 3 | 233 | 1911097 | 6079.54 | 1351 | 1355 | 314.1 |
| C | 0 | 10 | 450335 | 1429.3 | 1351 | 1355 | 314.1 |
| C | 14 | 238 | 270354 | 856.34 | 1351 | 1355 | 314.1 |
| D | 8 | 195 | 1014779 | 3051.51 | 1402 | 1360 | 332.1 |
| D | 12 | 233 | 397637 | 1193.23 | 1402 | 1360 | 332.1 |
| D | 12 | 218 | 148053 | 441.71 | 1402 | 1360 | 332.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
