| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A09_131T01_9000004690_32181cztM0_level2.evt | modeM0/AS1A09_131T01_9000004690_32181cztM0_level2_quad_clean.evt |
| Size (bytes) | 164,986,560 | 41,806,080 |
| Size | 157.3 MB | 39.9 MB |
| Events in quadrant A | 975,715 | 285,366 |
| Events in quadrant B | 1,507,362 | 275,829 |
| Events in quadrant C | 1,052,909 | 283,641 |
| Events in quadrant D | 1,316,679 | 269,683 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 49 | 4 |
| B | 0 | 50 | 2 |
| C | 0 | 51 | 5 |
| D | 0 | 52 | 4 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 5078 | 775 |
| B | 0 | 7556 | 1482 |
| C | 0 | 5298 | 827 |
| D | 0 | 6554 | 1248 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 1 | 0 |
| B | 0 | 1 | 0 |
| C | 0 | 2 | 1 |
| D | 0 | 1 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 2102 | 9 | 0.428164% |
| B | 2013 | 45 | 2.235469% |
| C | 2095 | 43 | 2.052506% |
| D | 2065 | 11 | 0.532688% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 19465 | 2201 | 0 | 0 | 0.00% | 0.00% |  |
| B | 19443 | 2121 | 0 | 0 | 0.00% | 0.00% |  |
| C | 19463 | 2181 | 2 | 2 | 0.01% | 0.09% |  |
| D | 19445 | 2157 | 6 | 6 | 0.03% | 0.28% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 6 | 3932 | 71.15 | 251 | 247 | 51.8 |
| A | 13 | 254 | 3583 | 64.41 | 251 | 247 | 51.8 |
| A | 3 | 137 | 2525 | 43.98 | 251 | 247 | 51.8 |
| B | 6 | 159 | 538538 | 11253.48 | 240 | 234 | 47.8 |
| B | 15 | 33 | 8707 | 177.13 | 240 | 234 | 47.8 |
| B | 0 | 190 | 6461 | 130.18 | 240 | 234 | 47.8 |
| C | 0 | 10 | 53720 | 948.59 | 239 | 240 | 56.4 |
| C | 14 | 238 | 44073 | 777.48 | 239 | 240 | 56.4 |
| C | 4 | 175 | 6230 | 106.25 | 239 | 240 | 56.4 |
| D | 8 | 195 | 380771 | 6720.49 | 233 | 226 | 56.6 |
| D | 2 | 250 | 44969 | 790.17 | 233 | 226 | 56.6 |
| D | 2 | 234 | 7192 | 123.02 | 233 | 226 | 56.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
