| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A09_131T01_9000004696_32281cztM0_level2.evt | modeM0/AS1A09_131T01_9000004696_32281cztM0_level2_quad_clean.evt |
| Size (bytes) | 640,569,600 | 128,583,360 |
| Size | 610.9 MB | 122.6 MB |
| Events in quadrant A | 3,189,860 | 874,847 |
| Events in quadrant B | 5,454,034 | 886,726 |
| Events in quadrant C | 3,715,976 | 871,719 |
| Events in quadrant D | 6,593,491 | 800,380 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 136 | 0 |
| B | 0 | 136 | 0 |
| C | 0 | 136 | 0 |
| D | 0 | 136 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16 | 0 |
| B | 0 | 16 | 0 |
| C | 0 | 16 | 0 |
| D | 0 | 17 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13818 | 3 |
| B | 0 | 20953 | 2 |
| C | 0 | 15336 | 2 |
| D | 0 | 24112 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6600 | 33 | 0.500000% |
| B | 6600 | 187 | 2.833333% |
| C | 6600 | 263 | 3.984848% |
| D | 6600 | 511 | 7.742424% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7835 | 6601 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7835 | 6601 | 8 | 8 | 0.10% | 0.12% |  |
| C | 7835 | 6601 | 43 | 43 | 0.55% | 0.65% |  |
| D | 7835 | 6601 | 301 | 301 | 3.84% | 4.56% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 6 | 25929 | 155.75 | 816 | 802 | 161.3 |
| A | 13 | 254 | 11985 | 69.32 | 816 | 802 | 161.3 |
| A | 2 | 79 | 8003 | 44.64 | 816 | 802 | 161.3 |
| B | 6 | 159 | 1908051 | 12539.53 | 819 | 800 | 152.1 |
| B | 0 | 190 | 121597 | 794.2 | 819 | 800 | 152.1 |
| B | 0 | 229 | 51924 | 336.12 | 819 | 800 | 152.1 |
| C | 0 | 10 | 178313 | 970.04 | 793 | 796 | 183.0 |
| C | 3 | 233 | 170051 | 924.9 | 793 | 796 | 183.0 |
| C | 14 | 238 | 150296 | 816.94 | 793 | 796 | 183.0 |
| D | 8 | 195 | 2714108 | 14985.68 | 767 | 747 | 181.1 |
| D | 13 | 249 | 438754 | 2419.08 | 767 | 747 | 181.1 |
| D | 12 | 233 | 179764 | 988.7 | 767 | 747 | 181.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
