| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_005T01_9000004700_32321cztM0_level2.evt | modeM0/AS1A10_005T01_9000004700_32321cztM0_level2_quad_clean.evt |
| Size (bytes) | 808,156,800 | 87,552,000 |
| Size | 770.7 MB | 83.5 MB |
| Events in quadrant A | 3,062,881 | 616,912 |
| Events in quadrant B | 5,971,514 | 582,833 |
| Events in quadrant C | 7,601,710 | 501,006 |
| Events in quadrant D | 7,429,422 | 524,199 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12971 | 2 |
| B | 0 | 22207 | 1 |
| C | 0 | 26789 | 1 |
| D | 0 | 26153 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 124 | 0 |
| B | 0 | 124 | 0 |
| C | 0 | 124 | 0 |
| D | 0 | 124 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6092 | 48 | 0.787919% |
| B | 6092 | 471 | 7.731451% |
| C | 6092 | 1750 | 28.726198% |
| D | 6092 | 713 | 11.703874% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7312 | 6093 | 1 | 1 | 0.01% | 0.02% |  |
| B | 7312 | 6093 | 225 | 225 | 3.08% | 3.69% |  |
| C | 7312 | 6093 | 1011 | 1011 | 13.83% | 16.59% |  |
| D | 7312 | 6093 | 607 | 607 | 8.30% | 9.96% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 6 | 38365 | 242.77 | 777 | 763 | 154.9 |
| A | 13 | 6 | 14175 | 86.59 | 777 | 763 | 154.9 |
| A | 13 | 254 | 12524 | 75.93 | 777 | 763 | 154.9 |
| B | 6 | 159 | 1998690 | 14192.83 | 755 | 737 | 140.8 |
| B | 5 | 172 | 772513 | 5482.45 | 755 | 737 | 140.8 |
| B | 0 | 190 | 107426 | 757.89 | 755 | 737 | 140.8 |
| C | 0 | 10 | 3325530 | 21410.29 | 667 | 671 | 155.3 |
| C | 3 | 233 | 1463573 | 9420.3 | 667 | 671 | 155.3 |
| C | 14 | 238 | 108775 | 696.13 | 667 | 671 | 155.3 |
| D | 8 | 195 | 3003799 | 17516.04 | 721 | 704 | 171.4 |
| D | 13 | 249 | 701067 | 4084.98 | 721 | 704 | 171.4 |
| D | 12 | 6 | 453929 | 2643.51 | 721 | 704 | 171.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
