| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_005T01_9000004700_32337cztM0_level2.evt | modeM0/AS1A10_005T01_9000004700_32337cztM0_level2_quad_clean.evt |
| Size (bytes) | 651,677,760 | 93,810,240 |
| Size | 621.5 MB | 89.5 MB |
| Events in quadrant A | 3,117,108 | 639,052 |
| Events in quadrant B | 6,073,212 | 609,382 |
| Events in quadrant C | 3,698,641 | 603,902 |
| Events in quadrant D | 6,438,762 | 565,183 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12976 | 2 |
| B | 0 | 22371 | 1 |
| C | 0 | 14758 | 1 |
| D | 0 | 23644 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 124 | 0 |
| B | 0 | 124 | 0 |
| C | 0 | 124 | 0 |
| D | 0 | 124 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6055 | 20 | 0.330306% |
| B | 6055 | 469 | 7.745665% |
| C | 6055 | 156 | 2.576383% |
| D | 6055 | 358 | 5.912469% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7400 | 6056 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7400 | 6056 | 285 | 285 | 3.85% | 4.71% |  |
| C | 7400 | 6056 | 59 | 59 | 0.80% | 0.97% |  |
| D | 7400 | 6056 | 328 | 328 | 4.43% | 5.42% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 189 | 30266 | 187.67 | 793 | 778 | 157.1 |
| A | 13 | 6 | 20652 | 126.49 | 793 | 778 | 157.1 |
| A | 13 | 254 | 11615 | 68.97 | 793 | 778 | 157.1 |
| B | 6 | 159 | 1924906 | 13535.75 | 772 | 755 | 142.2 |
| B | 5 | 172 | 870641 | 6119.35 | 772 | 755 | 142.2 |
| B | 0 | 190 | 86934 | 606.24 | 772 | 755 | 142.2 |
| C | 0 | 10 | 207046 | 1167.1 | 761 | 770 | 176.7 |
| C | 3 | 233 | 187711 | 1057.7 | 761 | 770 | 176.7 |
| C | 14 | 238 | 126542 | 711.61 | 761 | 770 | 176.7 |
| D | 8 | 195 | 2890322 | 16199.57 | 756 | 737 | 178.4 |
| D | 11 | 164 | 331257 | 1852.96 | 756 | 737 | 178.4 |
| D | 12 | 233 | 128017 | 713.56 | 756 | 737 | 178.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
