| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A09_108T02_9000004706_32433cztM0_level2.evt | modeM0/AS1A09_108T02_9000004706_32433cztM0_level2_quad_clean.evt |
| Size (bytes) | 592,485,120 | 73,560,960 |
| Size | 565.0 MB | 70.2 MB |
| Events in quadrant A | 3,271,254 | 445,142 |
| Events in quadrant B | 6,178,590 | 454,523 |
| Events in quadrant C | 3,578,753 | 430,857 |
| Events in quadrant D | 4,449,203 | 417,326 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 142 | 0 |
| B | 0 | 142 | 0 |
| C | 0 | 142 | 0 |
| D | 0 | 142 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 13 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14020 | 3 |
| B | 0 | 23048 | 2 |
| C | 0 | 14871 | 2 |
| D | 0 | 17704 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6870 | 64 | 0.931587% |
| B | 6870 | 234 | 3.406114% |
| C | 6870 | 239 | 3.478894% |
| D | 6870 | 323 | 4.701601% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7735 | 6871 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7735 | 6871 | 34 | 34 | 0.44% | 0.49% |  |
| C | 7735 | 6871 | 7 | 7 | 0.09% | 0.10% |  |
| D | 7735 | 6871 | 254 | 254 | 3.28% | 3.70% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 6 | 10828 | 58.87 | 845 | 827 | 169.9 |
| A | 13 | 254 | 10293 | 55.72 | 845 | 827 | 169.9 |
| A | 3 | 137 | 9057 | 48.45 | 845 | 827 | 169.9 |
| B | 6 | 159 | 1862258 | 11451.56 | 835 | 813 | 162.5 |
| B | 4 | 80 | 1026730 | 6311.42 | 835 | 813 | 162.5 |
| B | 12 | 111 | 20663 | 122.12 | 835 | 813 | 162.5 |
| C | 14 | 238 | 171158 | 907.22 | 800 | 804 | 187.8 |
| C | 14 | 254 | 62077 | 326.31 | 800 | 804 | 187.8 |
| C | 0 | 10 | 56536 | 296.8 | 800 | 804 | 187.8 |
| D | 14 | 52 | 768394 | 3971.3 | 806 | 784 | 193.3 |
| D | 1 | 47 | 201285 | 1037.31 | 806 | 784 | 193.3 |
| D | 2 | 250 | 148014 | 761.71 | 806 | 784 | 193.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
