| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_057T03_9000004722_32673cztM0_level2.evt | modeM0/AS1A10_057T03_9000004722_32673cztM0_level2_quad_clean.evt |
| Size (bytes) | 703,768,320 | 54,322,560 |
| Size | 671.2 MB | 51.8 MB |
| Events in quadrant A | 3,285,902 | 343,056 |
| Events in quadrant B | 4,398,865 | 336,958 |
| Events in quadrant C | 3,480,434 | 343,651 |
| Events in quadrant D | 9,805,372 | 264,204 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12867 | 3 |
| B | 0 | 16458 | 2 |
| C | 0 | 13524 | 2 |
| D | 0 | 32588 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 20 | 0 |
| B | 0 | 20 | 0 |
| C | 0 | 20 | 0 |
| D | 0 | 20 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 104 | 0 |
| B | 0 | 104 | 0 |
| C | 0 | 104 | 0 |
| D | 0 | 104 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5079 | 259 | 5.099429% |
| B | 5079 | 381 | 7.501477% |
| C | 5079 | 210 | 4.134672% |
| D | 5080 | 3130 | 61.614173% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7052 | 5080 | 203 | 203 | 2.88% | 4.00% |  |
| B | 7052 | 5080 | 334 | 334 | 4.74% | 6.57% |  |
| C | 7052 | 5080 | 182 | 182 | 2.58% | 3.58% |  |
| D | 7053 | 5081 | 2919 | 2919 | 41.39% | 57.45% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 249 | 844044 | 6965.77 | 604 | 593 | 121.1 |
| A | 14 | 239 | 33922 | 275.25 | 604 | 593 | 121.1 |
| A | 12 | 189 | 17831 | 142.36 | 604 | 593 | 121.1 |
| B | 0 | 255 | 778115 | 6841.9 | 600 | 589 | 113.6 |
| B | 3 | 26 | 442422 | 3887.94 | 600 | 589 | 113.6 |
| B | 0 | 219 | 442254 | 3886.47 | 600 | 589 | 113.6 |
| C | 9 | 236 | 800459 | 5935.25 | 583 | 589 | 134.8 |
| C | 0 | 10 | 197406 | 1460.44 | 583 | 589 | 134.8 |
| C | 8 | 35 | 34994 | 255.29 | 583 | 589 | 134.8 |
| D | 7 | 38 | 5642044 | 61490.54 | 384 | 376 | 91.7 |
| D | 8 | 195 | 499502 | 5440.15 | 384 | 376 | 91.7 |
| D | 2 | 249 | 355964 | 3875.68 | 384 | 376 | 91.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
