| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_057T03_9000004722_32685cztM0_level2.evt | modeM0/AS1A10_057T03_9000004722_32685cztM0_level2_quad_clean.evt |
| Size (bytes) | 780,436,800 | 59,123,520 |
| Size | 744.3 MB | 56.4 MB |
| Events in quadrant A | 10,400,958 | 170,984 |
| Events in quadrant B | 2,744,760 | 451,209 |
| Events in quadrant C | 2,949,699 | 432,120 |
| Events in quadrant D | 7,201,112 | 381,442 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 34348 | 2 |
| B | 0 | 11026 | 1 |
| C | 0 | 11831 | 1 |
| D | 0 | 24889 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 21 | 0 |
| B | 0 | 21 | 0 |
| C | 0 | 21 | 0 |
| D | 0 | 21 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 102 | 0 |
| B | 0 | 102 | 0 |
| C | 0 | 102 | 0 |
| D | 0 | 102 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5031 | 3107 | 61.757106% |
| B | 5031 | 10 | 0.198768% |
| C | 5031 | 84 | 1.669648% |
| D | 5031 | 1623 | 32.259988% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7154 | 5031 | 2906 | 2906 | 40.62% | 57.76% |  |
| B | 7154 | 5031 | 6 | 6 | 0.08% | 0.12% |  |
| C | 7154 | 5031 | 80 | 80 | 1.12% | 1.59% |  |
| D | 7154 | 5031 | 1427 | 1427 | 19.95% | 28.36% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 249 | 8682579 | 101817.73 | 427 | 420 | 85.3 |
| A | 7 | 16 | 52714 | 613.26 | 427 | 420 | 85.3 |
| A | 13 | 254 | 6248 | 68.35 | 427 | 420 | 85.3 |
| B | 3 | 32 | 80815 | 669.32 | 638 | 625 | 119.8 |
| B | 5 | 172 | 31174 | 254.98 | 638 | 625 | 119.8 |
| B | 0 | 230 | 27847 | 227.21 | 638 | 625 | 119.8 |
| C | 9 | 236 | 234867 | 1680.77 | 607 | 613 | 139.4 |
| C | 0 | 10 | 144131 | 1029.74 | 607 | 613 | 139.4 |
| C | 0 | 207 | 41934 | 296.48 | 607 | 613 | 139.4 |
| D | 7 | 38 | 2009039 | 16313.02 | 522 | 512 | 123.1 |
| D | 7 | 80 | 915811 | 7433.95 | 522 | 512 | 123.1 |
| D | 4 | 239 | 710003 | 5762.4 | 522 | 512 | 123.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
