| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A10_057T04_9000004728_32748cztM0_level2.evt | modeM0/AS1A10_057T04_9000004728_32748cztM0_level2_quad_clean.evt |
| Size (bytes) | 484,931,520 | 61,341,120 |
| Size | 462.5 MB | 58.5 MB |
| Events in quadrant A | 3,756,681 | 363,324 |
| Events in quadrant B | 3,443,578 | 362,968 |
| Events in quadrant C | 3,152,601 | 362,501 |
| Events in quadrant D | 3,925,081 | 347,951 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15060 | 2 |
| B | 0 | 14006 | 1 |
| C | 0 | 13294 | 1 |
| D | 0 | 15461 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 20 | 0 |
| B | 0 | 20 | 0 |
| C | 0 | 20 | 0 |
| D | 0 | 21 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 120 | 0 |
| B | 0 | 120 | 0 |
| C | 0 | 120 | 0 |
| D | 0 | 120 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6026 | 217 | 3.601062% |
| B | 6026 | 71 | 1.178228% |
| C | 6026 | 67 | 1.111849% |
| D | 6026 | 150 | 2.489213% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7340 | 6027 | 157 | 157 | 2.14% | 2.60% |  |
| B | 7340 | 6027 | 42 | 42 | 0.57% | 0.70% |  |
| C | 7340 | 6027 | 59 | 59 | 0.80% | 0.98% |  |
| D | 7340 | 6027 | 120 | 120 | 1.63% | 1.99% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 249 | 1028782 | 7395.11 | 693 | 678 | 139.0 |
| A | 0 | 254 | 19860 | 137.98 | 693 | 678 | 139.0 |
| A | 9 | 143 | 11343 | 76.71 | 693 | 678 | 139.0 |
| B | 12 | 1 | 213715 | 1586.0 | 702 | 686 | 134.3 |
| B | 0 | 219 | 130996 | 970.16 | 702 | 686 | 134.3 |
| B | 5 | 172 | 103776 | 767.51 | 702 | 686 | 134.3 |
| C | 8 | 229 | 139325 | 878.38 | 678 | 683 | 157.8 |
| C | 8 | 79 | 126777 | 798.88 | 678 | 683 | 157.8 |
| C | 0 | 10 | 118738 | 747.95 | 678 | 683 | 157.8 |
| D | 2 | 250 | 287200 | 1701.82 | 673 | 656 | 168.4 |
| D | 8 | 195 | 227782 | 1348.93 | 673 | 656 | 168.4 |
| D | 12 | 233 | 226310 | 1340.19 | 673 | 656 | 168.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
