| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T04_064T01_9000004730_32785cztM0_level2.evt | modeM0/AS1T04_064T01_9000004730_32785cztM0_level2_quad_clean.evt |
| Size (bytes) | 716,696,640 | 52,925,760 |
| Size | 683.5 MB | 50.5 MB |
| Events in quadrant A | 3,962,852 | 298,487 |
| Events in quadrant B | 4,075,460 | 335,680 |
| Events in quadrant C | 3,505,471 | 341,480 |
| Events in quadrant D | 9,804,215 | 254,285 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 20 | 0 |
| B | 0 | 20 | 0 |
| C | 0 | 20 | 0 |
| D | 0 | 20 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 108 | 0 |
| B | 0 | 108 | 0 |
| C | 0 | 108 | 0 |
| D | 0 | 108 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14848 | 3 |
| B | 0 | 15673 | 2 |
| C | 0 | 13432 | 2 |
| D | 0 | 32795 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5305 | 514 | 9.688973% |
| B | 5305 | 278 | 5.240339% |
| C | 5305 | 244 | 4.599434% |
| D | 5306 | 2003 | 37.749717% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7277 | 5306 | 392 | 392 | 5.39% | 7.39% |  |
| B | 7277 | 5306 | 172 | 172 | 2.36% | 3.24% |  |
| C | 7277 | 5306 | 183 | 183 | 2.51% | 3.45% |  |
| D | 7278 | 5307 | 1923 | 1923 | 26.42% | 36.24% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 237 | 1196536 | 8879.81 | 681 | 672 | 134.7 |
| A | 14 | 238 | 70723 | 520.16 | 681 | 672 | 134.7 |
| A | 15 | 174 | 18104 | 129.44 | 681 | 672 | 134.7 |
| B | 0 | 219 | 417210 | 3179.51 | 706 | 692 | 131.0 |
| B | 5 | 172 | 413010 | 3147.45 | 706 | 692 | 131.0 |
| B | 12 | 1 | 250712 | 1908.54 | 706 | 692 | 131.0 |
| C | 0 | 10 | 667015 | 4303.84 | 680 | 688 | 154.8 |
| C | 3 | 233 | 50994 | 324.93 | 680 | 688 | 154.8 |
| C | 15 | 159 | 37391 | 237.07 | 680 | 688 | 154.8 |
| D | 8 | 195 | 5036140 | 30959.19 | 621 | 609 | 162.7 |
| D | 2 | 250 | 654949 | 4022.98 | 621 | 609 | 162.7 |
| D | 14 | 52 | 649106 | 3987.06 | 621 | 609 | 162.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
