| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1T04_064T01_9000004730_32805cztM0_level2.evt | modeM0/AS1T04_064T01_9000004730_32805cztM0_level2_quad_clean.evt |
| Size (bytes) | 539,092,800 | 82,690,560 |
| Size | 514.1 MB | 78.9 MB |
| Events in quadrant A | 2,725,569 | 542,301 |
| Events in quadrant B | 3,987,069 | 534,743 |
| Events in quadrant C | 3,452,088 | 537,553 |
| Events in quadrant D | 5,778,148 | 492,844 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14 | 0 |
| B | 0 | 14 | 0 |
| C | 0 | 14 | 0 |
| D | 0 | 15 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 116 | 0 |
| B | 0 | 116 | 0 |
| C | 0 | 116 | 0 |
| D | 0 | 116 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11643 | 3 |
| B | 0 | 15472 | 2 |
| C | 0 | 13831 | 2 |
| D | 0 | 21104 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5665 | 12 | 0.211827% |
| B | 5665 | 222 | 3.918800% |
| C | 5665 | 122 | 2.153575% |
| D | 5665 | 397 | 7.007944% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7098 | 5666 | 3 | 3 | 0.04% | 0.05% |  |
| B | 7098 | 5666 | 141 | 141 | 1.99% | 2.49% |  |
| C | 7098 | 5666 | 93 | 93 | 1.31% | 1.64% |  |
| D | 7098 | 5666 | 408 | 408 | 5.75% | 7.20% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 7 | 16 | 66732 | 483.43 | 676 | 663 | 136.7 |
| A | 9 | 143 | 22819 | 162.12 | 676 | 663 | 136.7 |
| A | 13 | 254 | 11463 | 79.02 | 676 | 663 | 136.7 |
| B | 5 | 172 | 575319 | 4431.75 | 669 | 653 | 129.7 |
| B | 0 | 197 | 252945 | 1945.64 | 669 | 653 | 129.7 |
| B | 15 | 54 | 218879 | 1682.93 | 669 | 653 | 129.7 |
| C | 0 | 10 | 643301 | 4264.92 | 648 | 656 | 150.7 |
| C | 3 | 233 | 98781 | 651.21 | 648 | 656 | 150.7 |
| C | 0 | 207 | 87801 | 578.34 | 648 | 656 | 150.7 |
| D | 8 | 195 | 1594556 | 10292.5 | 637 | 623 | 154.9 |
| D | 2 | 250 | 576955 | 3721.55 | 637 | 623 | 154.9 |
| D | 2 | 249 | 285372 | 1838.71 | 637 | 623 | 154.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
