| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C06_002T09_9000004734_32834cztM0_level2.evt | modeM0/AS1C06_002T09_9000004734_32834cztM0_level2_quad_clean.evt |
| Size (bytes) | 517,449,600 | 93,876,480 |
| Size | 493.5 MB | 89.5 MB |
| Events in quadrant A | 2,572,387 | 642,312 |
| Events in quadrant B | 3,943,588 | 614,657 |
| Events in quadrant C | 2,851,948 | 617,821 |
| Events in quadrant D | 5,917,739 | 570,232 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 19 | 0 |
| B | 0 | 19 | 0 |
| C | 0 | 19 | 0 |
| D | 0 | 20 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11455 | 3 |
| B | 0 | 15368 | 2 |
| C | 0 | 12298 | 2 |
| D | 0 | 21596 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 116 | 0 |
| B | 0 | 116 | 0 |
| C | 0 | 116 | 0 |
| D | 0 | 116 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5689 | 4 | 0.070311% |
| B | 5689 | 347 | 6.099490% |
| C | 5689 | 38 | 0.667956% |
| D | 5689 | 304 | 5.343646% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7092 | 5690 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7092 | 5690 | 227 | 227 | 3.20% | 3.99% |  |
| C | 7092 | 5690 | 30 | 30 | 0.42% | 0.53% |  |
| D | 7092 | 5690 | 264 | 264 | 3.72% | 4.64% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 14 | 207 | 15743 | 115.0 | 653 | 641 | 131.3 |
| A | 9 | 143 | 12101 | 87.27 | 653 | 641 | 131.3 |
| A | 13 | 254 | 10504 | 75.11 | 653 | 641 | 131.3 |
| B | 5 | 172 | 890070 | 7433.62 | 633 | 618 | 119.7 |
| B | 0 | 219 | 189956 | 1582.4 | 633 | 618 | 119.7 |
| B | 8 | 128 | 188740 | 1572.24 | 633 | 618 | 119.7 |
| C | 0 | 10 | 130695 | 903.34 | 626 | 630 | 144.0 |
| C | 1 | 241 | 107266 | 740.62 | 626 | 630 | 144.0 |
| C | 3 | 233 | 82629 | 569.51 | 626 | 630 | 144.0 |
| D | 8 | 195 | 1887016 | 12653.36 | 615 | 602 | 149.1 |
| D | 10 | 203 | 420265 | 2814.94 | 615 | 602 | 149.1 |
| D | 12 | 6 | 404198 | 2707.17 | 615 | 602 | 149.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
