| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A11_005T05_9000004744_32897cztM0_level2.evt | modeM0/AS1A11_005T05_9000004744_32897cztM0_level2_quad_clean.evt |
| Size (bytes) | 2,400,120,000 | 391,360,320 |
| Size | 2.2 GB | 373.2 MB |
| Events in quadrant A | 12,696,551 | 2,576,399 |
| Events in quadrant B | 19,441,883 | 2,521,949 |
| Events in quadrant C | 13,555,366 | 2,595,722 |
| Events in quadrant D | 25,239,156 | 2,364,138 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 536 | 0 |
| B | 0 | 536 | 0 |
| C | 0 | 536 | 0 |
| D | 0 | 536 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 85 | 0 |
| B | 0 | 85 | 0 |
| C | 0 | 85 | 0 |
| D | 0 | 85 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 54944 | 7 |
| B | 0 | 74852 | 6 |
| C | 0 | 56290 | 6 |
| D | 0 | 93853 | 6 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 26094 | 60 | 0.229938% |
| B | 26094 | 2327 | 8.917759% |
| C | 26094 | 180 | 0.689814% |
| D | 26094 | 1325 | 5.077796% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 34690 | 26099 | 13 | 13 | 0.04% | 0.05% |  |
| B | 34690 | 26099 | 1610 | 1610 | 4.64% | 6.17% |  |
| C | 34690 | 26099 | 136 | 136 | 0.39% | 0.52% |  |
| D | 34690 | 26099 | 1078 | 1078 | 3.11% | 4.13% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 14 | 63 | 803184 | 1328.39 | 3030 | 2966 | 602.4 |
| A | 7 | 16 | 64091 | 101.47 | 3030 | 2966 | 602.4 |
| A | 13 | 6 | 52504 | 82.23 | 3030 | 2966 | 602.4 |
| B | 5 | 31 | 3042084 | 5468.47 | 2950 | 2870 | 555.8 |
| B | 5 | 172 | 2816279 | 5062.18 | 2950 | 2870 | 555.8 |
| B | 5 | 15 | 896868 | 1608.57 | 2950 | 2870 | 555.8 |
| C | 14 | 67 | 647771 | 942.55 | 2973 | 3000 | 684.1 |
| C | 0 | 10 | 484545 | 703.94 | 2973 | 3000 | 684.1 |
| C | 3 | 233 | 329552 | 477.37 | 2973 | 3000 | 684.1 |
| D | 8 | 195 | 5715221 | 7823.96 | 2888 | 2828 | 730.1 |
| D | 2 | 250 | 2695518 | 3688.04 | 2888 | 2828 | 730.1 |
| D | 10 | 203 | 1391511 | 1902.01 | 2888 | 2828 | 730.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
