| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C07_005T01_9000004748_32925cztM0_level2.evt | modeM0/AS1C07_005T01_9000004748_32925cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,685,427,840 | 280,123,200 |
| Size | 1.6 GB | 267.1 MB |
| Events in quadrant A | 7,038,001 | 1,929,408 |
| Events in quadrant B | 10,523,424 | 1,897,592 |
| Events in quadrant C | 8,812,419 | 1,912,529 |
| Events in quadrant D | 23,624,492 | 1,670,151 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 318 | 0 |
| B | 0 | 318 | 0 |
| C | 0 | 318 | 0 |
| D | 0 | 318 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 42 | 0 |
| B | 0 | 42 | 0 |
| C | 0 | 42 | 0 |
| D | 0 | 42 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 31364 | 4 |
| B | 0 | 41526 | 3 |
| C | 0 | 36396 | 3 |
| D | 0 | 81109 | 3 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 15561 | 17 | 0.109247% |
| B | 15561 | 802 | 5.153910% |
| C | 15561 | 438 | 2.814729% |
| D | 15561 | 2921 | 18.771287% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 19769 | 15564 | 2 | 2 | 0.01% | 0.01% |  |
| B | 19769 | 15564 | 489 | 489 | 2.47% | 3.14% |  |
| C | 19769 | 15564 | 360 | 360 | 1.82% | 2.31% |  |
| D | 19769 | 15564 | 3191 | 3191 | 16.14% | 20.50% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 11 | 29 | 71193 | 194.21 | 1787 | 1749 | 357.6 |
| A | 13 | 254 | 27909 | 73.16 | 1787 | 1749 | 357.6 |
| A | 13 | 6 | 22157 | 57.07 | 1787 | 1749 | 357.6 |
| B | 5 | 172 | 1930655 | 5841.11 | 1752 | 1706 | 330.2 |
| B | 0 | 199 | 722704 | 2183.28 | 1752 | 1706 | 330.2 |
| B | 0 | 219 | 271092 | 815.74 | 1752 | 1706 | 330.2 |
| C | 9 | 187 | 895107 | 2265.63 | 1714 | 1727 | 394.3 |
| C | 0 | 10 | 635572 | 1607.45 | 1714 | 1727 | 394.3 |
| C | 14 | 67 | 286177 | 721.37 | 1714 | 1727 | 394.3 |
| D | 8 | 195 | 11078413 | 26444.47 | 1628 | 1592 | 418.9 |
| D | 12 | 227 | 1899808 | 4531.74 | 1628 | 1592 | 418.9 |
| D | 7 | 80 | 1186234 | 2828.18 | 1628 | 1592 | 418.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
