| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C07_005T01_9000004748_32933cztM0_level2.evt | modeM0/AS1C07_005T01_9000004748_32933cztM0_level2_quad_clean.evt |
| Size (bytes) | 441,118,080 | 103,685,760 |
| Size | 420.7 MB | 98.9 MB |
| Events in quadrant A | 2,471,704 | 703,899 |
| Events in quadrant B | 3,369,731 | 712,356 |
| Events in quadrant C | 2,573,081 | 712,910 |
| Events in quadrant D | 4,593,081 | 648,119 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 106 | 0 |
| B | 0 | 106 | 0 |
| C | 0 | 106 | 0 |
| D | 0 | 106 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 24 | 0 |
| B | 0 | 24 | 0 |
| C | 0 | 24 | 0 |
| D | 0 | 25 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 10651 | 3 |
| B | 0 | 13255 | 2 |
| C | 0 | 10817 | 2 |
| D | 0 | 17125 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5177 | 16 | 0.309059% |
| B | 5177 | 258 | 4.983581% |
| C | 5177 | 20 | 0.386324% |
| D | 5177 | 364 | 7.031099% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7240 | 5178 | 6 | 6 | 0.08% | 0.12% |  |
| B | 7240 | 5178 | 153 | 153 | 2.11% | 2.95% |  |
| C | 7240 | 5178 | 10 | 10 | 0.14% | 0.19% |  |
| D | 7240 | 5178 | 275 | 275 | 3.80% | 5.31% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 191 | 30550 | 244.77 | 613 | 601 | 122.4 |
| A | 7 | 16 | 28512 | 228.12 | 613 | 601 | 122.4 |
| A | 14 | 238 | 17733 | 140.02 | 613 | 601 | 122.4 |
| B | 5 | 172 | 590461 | 5177.82 | 611 | 598 | 113.9 |
| B | 0 | 199 | 175629 | 1536.42 | 611 | 598 | 113.9 |
| B | 10 | 246 | 56542 | 491.08 | 611 | 598 | 113.9 |
| C | 0 | 10 | 138988 | 986.22 | 611 | 617 | 140.3 |
| C | 14 | 67 | 15157 | 103.63 | 611 | 617 | 140.3 |
| C | 7 | 247 | 10924 | 73.46 | 611 | 617 | 140.3 |
| D | 8 | 195 | 886394 | 5930.42 | 585 | 572 | 149.4 |
| D | 7 | 80 | 367877 | 2459.04 | 585 | 572 | 149.4 |
| D | 2 | 250 | 335521 | 2242.42 | 585 | 572 | 149.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
